16/90 Accessories for control panel building
Meters, closing and locking systems
2010 CA08103002Z-EN
Meters,closingand locking systemsInsulated individual terminals 32 - 100 A
K…/1
Ammeters, voltmeters
EQ
BIEQ
Meters for DIN rails, analog Meters for DIN rails, digital
Z-MG/VA... Z-MG/VD...
Z-MG/AA... Z-MG/AD...
Comfort hinged handle
DH-COMF Mounting hole
Comfort rotary handles
PHZ-A-... Mounting hole
a
b1
5.5
c
b
Part no. a b b1 c
K10/1 11 60 50 30
K25/1 14 60 50 33
K50/1 18 60 50 36
a
a
c b a b c
EQ 45 45 47 5
EQ 48 DIN 48 53 5
EQ, BIEQ 72 72 64 5
EQ, BIEQ 96 96 64 5
