Accessories for control panel building
Cable glands, grommets
2010 CA08103002Z-EN
www.eaton.com16/87
Cableglands,grommets
Dimensions
Cable glands, metric
V-M…
Multiple gaskets
Sealing plugs
MFD…
MFV…
Cable screw glands
STB-M…F
Pressure compensating plugs
DAV-M40
DA412
Diaphragm grommets, metric
KT-M…
a
b
d
g
f
e
c
Part no.
a b c
d e
f
g
V-M12 16 18 M12x1.5 9
5.3 14
29 … 34
V-M16 20 22 M16x1.5 9
5.5 16.5 31 … 37
V-M20 24 27 M20x1.5 10 6.1 20
36 … 45
V-M25 29 32 M25x1.5 10 8.1 20
38 … 47
V-M32 36 40 M32x1.5 12 10.1 20
42 … 51
V-M40 46 51 M40x1.5 12 11.1 29
52 … 65
V-M50 55 61 M50x1.5 14 12.1 33
59 … 72
V-M63 68 75 M63x1.5 15 12.1 36.5 64 … 78
a
Part no.
a
MFD25
5.0 - 6.0
MFD32
3.5 - 7.0
c
a
b
Part no.
a b c
MFV25-6 5.5 6
20
MFV32-7 7
8
20
h
i
j
e
d
a
c
b
f
g
Part no.
c h I
j
g f
b a d e
STB-M20F 20 5 15 40 29 27 23 21 24 27
STB-M25F 25 6 15 45 35.5 35.5 33.4 30 33 32
60
19
o
40
37
30.5
15.5
65.5
PG 29 (
o
37)
c
a
d
b
Part no.
a
b c
d
KT-M16
21.2 16 9.5 11
KT-M20
25.2 20 9.5 11
KT-M25
30.2 25 9.5 11
KT-M32
37.2 32 9.5 11
