16/82 Accessories for control panel building
Circuit diagram pockets, control panel illumination, hinged flaps
2010 CA08103002Z-EN
Circuitdiagrampockets,controlpanel illumination,hinged flaps
Features Part no.
Article no.
Price
See price list
Std. pack
Circuit diagram pockets, insulating material
• Made of plastic with self-adhesive back
• RAL 7035 light grey
DIN A4 landscape SPT4
002275
10 off
DIN A5 landscape SPT5
002276
10 off
DIN A6 landscape SPT6
002277
10 off
Circuit diagram pocket, metal
• For fitting to door porfile with M5 bolts
DIN A6 landscape XVTL-SPT6
115247
1 off
Description Part no.
Article no.
Price
See price list
Std. pack
Control panel illumination
Control panel lights
– XVTL-SRL/S
116892
1 off
With switches, socket and magnetic holder NWS-SRL/S/ST/MG
255355
1 off
Door contact switches
– NWS-TKT
255420
1 off
Mounted on retaining bracket NWS-TKT/M
285046
For use with Part no.
Article no.
Price
See price list
Std. pack
Hinged flaps
• For positioning on cover, change as required
• Degree of protection IP55
• Opening angle up to 180°
• Hinge on one side cannot be changed
• Transparent
145 x 80 mm K-A
043372
1 off
185 x 90 mm KG-A
055244
1 off
SPT, NWS-TKT, K-A HPL16082EN
