IZM circuit-breakers, IN switch-disconnectors
Accessories for IZM26
2010 CA08103002Z-EN
18/63
Rated
operational
current
For use with 3 pole Price
See price list
4 pole Price
See price list
Std.
pack
In
A Part no.
Article no.
Part no. suffix “+IZM...”
Article no. for ordering with
basic device
Part no.
Article no.
Part no. suffix “+IZM...”
Article no. for ordering with
basic device
Withdrawable units
Cassettes 1100 V in combination with basic device
Standard equipment:
• Arc chute cover
• Coding between cassette and switch
• Horizontal Connection
• Door seal
3200 IZM32…W-1100V
IN32…W-1100V
+IZM-CAS323-3200-1100V
122712
+IZM-CAS324-3200-1100V
122720
1 off
Cassettes 1100 V, ordered separately
Standard equipment:
• Arc chute cover
• Complete set of control circuit terminals
• Coding between cassette and switch
• Horizontal Connection
• Door seal
3200 IZM32…W-1100V
IN32…W-1100V
IZM-CAS323-3200-1100V
122862
IZM-CAS324-3200-1100V
122870
1 off
Shutter (touch protection)
When the switch is moved out of the CONNECT position,
the shutters close automatically to cover the primary contacts.
– IZM20…W
IN20…W
IZM-SH203
122871
IZM-SH204
122875
1 off
IZM20…W
IN20…W
+IZM-SH203
122721
+IZM-SH204
122725
IZM32…W
IN32…W
IZM-SH323
122872
IZM-SH324
122876
IZM32…W
IN32…W
+IZM-SH323
122722
+IZM-SH324
122726
IZM40…W
IN40…W
IZM-SH403
122873
IZM-SH404
122877
IZM40…W
IN40…W
+IZM-SH403
122723
+IZM-SH404
122727
IZM63…W
IN63…W
IZM-SH633
122874
IZM-SH634
122878
IZM63…W
IN63…W
+IZM-SH633
122724
+IZM-SH634
122728
IZM-CAS..., IZM-SH... HPL18063EN
