18/58 IZM circuit-breakers, IN switch-disconnectors
Air circuit-breakers, 4 pole
2010 CA08103002Z-EN
Aircircuit-breakers, 4pole
Switching
capacity
Rated
operational
current
Frame
size
Setting range Fixed mounted Withdrawable units
Overload
release
Short-circuit releases Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Std.
pack
Delayed Non-delayed
Icu = Ics In = Iu Ir Isd = Ir x … Ii = In x …
Cassettemust be
ordered sepa-
rately.
kA A A
Circuit-breaker for universal protection with power monitoring
Including main terminals at rear and control circuit terminals according to ordered options.
50 800 IZM20 320 – 800 2 - 10 2 - 10, OFF IZM20B4-P08F
123538
IZM20B4-P08W
123298
1 off
1000 400 – 1000 IZM20B4-P10F
123539
IZM20B4-P10W
123299
1250 500 – 1250 IZM20B4-P12F
123540
IZM20B4-P12W
123300
1600 640 – 1600 IZM20B4-P16F
123541
IZM20B4-P16W
123301
2000 800 – 2000 IZM20B4-P20F
123542
IZM20B4-P20W
123302
65 800 320 – 800 IZM20N4-P08F
123568
IZM20N4-P08W
123328
1000 400 – 1000 IZM20N4-P10F
123569
IZM20N4-P10W
123329
1250 500 – 1250 IZM20N4-P12F
123570
IZM20N4-P12W
123330
1600 640 – 1600 IZM20N4-P16F
123571
IZM20N4-P16W
123331
2000 800 – 2000 IZM20N4-P20F
123572
IZM20N4-P20W
123332
800 IZM32 320 – 800 IZM32B4-P08F
124068
IZM32B4-P08W
123778
1000 400 – 1000 IZM32B4-P10F
124069
IZM32B4-P10W
123779
1250 500 – 1250 IZM32B4-P12F
124070
IZM32B4-P12W
123780
1600 640 – 1600 IZM32B4-P16F
124071
IZM32B4-P16W
123781
2000 800 – 2000 IZM32B4-P20F
124072
IZM32B4-P20W
123782
2500 1000 – 2500 IZM32B4-P25F
124073
IZM32B4-P25W
123783
3200 1280 – 3200 IZM32B4-P32F
124074
IZM32B4-P32W
123784
85 800 320 – 800 IZM32N4-P08F
124108
IZM32N4-P08W
123818
1000 400 – 1000 IZM32N4-P10F
124109
IZM32N4-P10W
123819
1250 500 – 1250 IZM32N4-P12F
124110
IZM32N4-P12W
123820
1600 640 – 1600 IZM32N4-P16F
124111
IZM32N4-P16W
123821
2000 800 – 2000 IZM32N4-P20F
124112
IZM32N4-P20W
123822
2500 1000 – 2500 IZM32N4-P25F
124113
IZM32N4-P25W
123823
3200 1280 – 3200 IZM32N4-P32F
124114
IZM32N4-P32W
123824
4000 IZM40 1600 – 4000 IZM40N4-P40F
124366
IZM40N4-P40W
124256
4000 IZM63 1600 – 4000 IZM63N4-P40F
124367
IZM63N4-P40W
124257
5000 2000 – 5000 IZM63N4-P50F
124368
IZM63N4-P50W
124258
6300 2520 – 6300 IZM63N4-P63F
124369
IZM63N4-P63W
124259
I I
