383 / 543
IZM circuit-breakers, IN switch-disconnectors
3 pole air circuit-breakers/3 pole air circuit breakers 1100 V
2010 CA08103002Z-EN
www.eaton.com18/53
3 poleaircircuit-breakers/3poleaircircuitbreakers 1100V
Switching
capacity
Rated
operational
current
Frame
size
Setting range
Fixed mounted
Withdrawable units
Overload
release
Short-circuit releases
Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Std.
pack
Delayed
Non-delayed
I
cu
= I
cs
I
n
= I
u
I
r
I
sd
= I
r
x
… I
i
= I
n
x
…
Cassette must
be ordered
separately.
kA
A
A
Circuit-breaker for universal protection with power monitoring
Including main terminals at rear and control circuit terminals according to ordered options.
100
800
IZM32
320 – 800
2 - 10
2 - 10, OFF
IZM32H3-P08F
124003
IZM32H3-P08W
123713
1 off
1000
400 – 1000
IZM32H3-P10F
124004
IZM32H3-P10W
123714
1250
500 – 1250
IZM32H3-P12F
124005
IZM32H3-P12W
123715
1600
640 – 1600
IZM32H3-P16F
124006
IZM32H3-P16W
123716
2000
800 – 2000
IZM32H3-P20F
124007
IZM32H3-P20W
123717
2500
1000 – 2500
IZM32H3-P25F
124008
IZM32H3-P25W
123718
3200
1280 – 3200
IZM32H3-P32F
124009
IZM32H3-P32W
123719
4000
IZM40
1600 – 4000
IZM40H3-P40F
124331
IZM40H3-P40W
124221
4000
IZM63
1600 – 4000
IZM63H3-P40F
124332
IZM63H3-P40W
124222
5000
2000 – 5000
IZM63H3-P50F
124333
IZM63H3-P50W
124223
6300
2520 – 6300
IZM63H3-P63F
124334
IZM63H3-P63W
124224
Fixed mounted
Withdrawable units
Switching
capacity
Rated
operational
current
Setting range
Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Std.
pack
Overload
release
Short-circuit releases
Delayed
Non-delayed
Cassette must be
ordered separately.
I
cu
= I
cs
I
n
= I
u
I
r
I
sd
= I
r
x
… I
i
= I
n
x
…
kA
A
A
IZM32 for 1100 V
Including main terminals at rear and control circuit terminals according to
ordered options.
Circuit-breakers for system protection
25
3200
1280 – 3200 –
2 - 10
IZM32S3-A32F-1100V
123725
IZM32S3-A32W-1100V
123721
1 off
Selectively-opening circuit-breakers
25
3200
1280 – 3200 2 - 10
2 - 10, OFF
IZM32S3-V32F-1100V
123726
IZM32S3-V32W-1100V
123722
1 off
Circuit-breaker for universal protection
25
3200
1280 – 3200 2 - 10
2 - 10, OFF
IZM32S3-U32F-1100V
123727
IZM32S3-U32W-1100V
123723
1 off
Circuit-breaker with circuit-breaker
25
3200
1280 – 3200 2 - 10
2 - 10, OFF
IZM32S3-P32F-1100V
123749
IZM32S3-P32W-1100V
123724
1 off
I
I
I
I
IZM26
HPL18053EN
