Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

384 / 543

18/54 IZM circuit-breakers, IN switch-disconnectors
Air circuit-breakers, 4 pole
2010 CA08103002Z-EN
Aircircuit-breakers, 4pole
Switching
capacity
Rated
operational
current
Frame
size
Setting range Fixed mounted Withdrawable units
Overload
release
Short-circuit releases Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Std.
pack
Delayed Non-delayed
Icu = Ics In = Iu Ir Isd = Ir x … Ii = In x …
Cassettemust be
ordered sepa-
rately.
kA A A
Circuit-breakers for system protection
Including main terminals at rear and control circuit terminals according to ordered options.
50 800 IZM20 320 – 800 – 2 - 10 IZM20B4-A08F
123520
IZM20B4-A08W
123280
1 off
1000 400 – 1000 IZM20B4-A10F
123521
IZM20B4-A10W
123281
1250 500 – 1250 IZM20B4-A12F
123522
IZM20B4-A12W
123282
1600 640 – 1600 IZM20B4-A16F
123523
IZM20B4-A16W
123283
2000 800 – 2000 IZM20B4-A20F
123524
IZM20B4-A20W
123284
65 800 320 – 800 IZM20N4-A08F
123550
IZM20N4-A08W
123310
1000 400 – 1000 IZM20N4-A10F
123551
IZM20N4-A10W
123311
1250 500 – 1250 IZM20N4-A12F
123552
IZM20N4-A12W
123312
1600 640 – 1600 IZM20N4-A16F
123553
IZM20N4-A16W
123313
2000 800 – 2000 IZM20N4-A20F
123554
IZM20N4-A20W
123314
800 IZM32 320 – 800 IZM32B4-A08F
124044
IZM32B4-A08W
123754
1000 400 – 1000 IZM32B4-A10F
124045
IZM32B4-A10W
123755
1250 500 – 1250 IZM32B4-A12F
124046
IZM32B4-A12W
123756
1600 640 – 1600 IZM32B4-A16F
124047
IZM32B4-A16W
123757
2000 800 – 2000 IZM32B4-A20F
124048
IZM32B4-A20W
123758
2500 1000 – 2500 IZM32B4-A25F
124049
IZM32B4-A25W
123759
3200 1280 – 3200 IZM32B4-A32F
124050
IZM32B4-A32W
123760
85 800 320 – 800 IZM32N4-A08F
124084
IZM32N4-A08W
123794
1000 400 – 1000 IZM32N4-A10F
124085
IZM32N4-A10W
123795
1250 500 – 1250 IZM32N4-A12F
124086
IZM32N4-A12W
123796
1600 640 – 1600 IZM32N4-A16F
124087
IZM32N4-A16W
123797
2000 800 – 2000 IZM32N4-A20F
124088
IZM32N4-A20W
123798
2500 1000 – 2500 IZM32N4-A25F
124089
IZM32N4-A25W
123799
3200 1280 – 3200 IZM32N4-A32F
124090
IZM32N4-A32W
123800
100 800 320 – 800 IZM32H4-A08F
124124
IZM32H4-A08W
123834
1000 400 – 1000 IZM32H4-A10F
124125
IZM32H4-A10W
123835
1250 500 – 1250 IZM32H4-A12F
124126
IZM32H4-A12W
123836
1600 640 – 1600 IZM32H4-A16F
124127
IZM32H4-A16W
123837
2000 800 – 2000 IZM32H4-A20F
124128
IZM32H4-A20W
123838
2500 1000 – 2500 IZM32H4-A25F
124129
IZM32H4-A25W
123839
3200 1280 – 3200 IZM32H4-A32F
124130
IZM32H4-A32W
123840
I I
IZM26 HPL18054EN
