18/66 IZM circuit-breakers, IN switch-disconnectors
Accessories for IZM26
2010 CA08103002Z-EN
Rated control
voltage
For use with Part no.
Article no.
Part no. suffix
“+IZM...”
Article no. for
ordering with basic
device
Price
See price
list
Std.
pack
Notes
Us
V
Voltage releases
Undervoltage release
Can not be combined with a second shunt release.
– 24 DC IZM20, 32, 40, 63...
IN20, 32,40, 63...
IZM-UVR24DC
122946
1 off If ordered separately a
secondary terminal block
IZM‐SEC‐… is necessary for
connection. Order separately
if required. Terminal assign-
ment page 77
24 DC +IZM-UVR24DC
122748
32 DC IZM-UVR32DC
122947
32 DC +IZM-UVR32DC
122749
48 DC IZM-UVR48DC
122948
48 DC +IZM-UVR48DC
122750
60 DC IZM-UVR60DC
123970
60 DC +IZM-UVR60DC
123962
110 - 125 DC IZM-UVR110DC
122949
110 - 125 DC +IZM-UVR110DC
122751
220 - 250 DC IZM-UVR220DC
122950
220 - 250 DC +IZM-UVR220DC
122752
110 - 127 AC IZM-UVR110AC
122951
110 - 127 AC +IZM-UVR110AC
122753
208 - 240 AC IZM-UVR230AC
122952
208 - 240 AC +IZM-UVR230AC
122754
380 - 415 AC IZM-UVR400AC
122953
380 - 415 AC +IZM-UVR400AC
122755
Time delay modules
For combination with an undervoltage release.
Delay times: 0.1 s, 0.5 s, 1.0 s, 2.0 s
Only in combination
with IZM-UVR110AC
120 AC IZM20, 32, 40, 63...
IN20, 32,40, 63...
IZM-UVR-TD-120AC
122956
1 off –
Only in combination
with IZM-UVR230AC
230 AC IZM-UVR-TD-230AC
122957
1 off
IZM-UVR..., IZM-UVR-TD... HPL18066EN
