IZM circuit-breakers, IN switch-disconnectors
Accessories for IZM26
2010 CA08103002Z-EN
www.eaton.com18/69
Accessories for IZM26
For use with
Part no.
Article no.
Price
See price
list
Std.
pack
Locking facilities
Mechanical interlock, fixed mounting
Type 2, for 2 circuit-breakers: A normal power supply (A) and an
emergency mains supply (B). 1 set of cables also required.
IZM20, 32, 40, 63...F
IN20, 32, 40, 63...F
IZM-MIL2C-F
122980
1 off
Type 31, for 3 circuit-breakers: Two normal power supplies (A, C)
and an emergency network supply (B). When B in Off,
A and C can be switched on. B can be switched on only when A
and C are in Off. Two sets of cables required in addition.
IZM-MIL31C-F
122981
Type 32, for 3 circuit-breakers: Two normal power supplies (A, C)
and a coupling (B). Any one or two circuit-breakers can be closed
at the same time. Three sets of cables are required in addition.
IZM-MIL32C-F
122982
Type 33, for 3 circuit-breakers: Three power supplies (A, B, C),
normal or emergency network. Only one of the three circuit-
breakers can be switched on at any one time. Three sets of cables
are required in addition.
IZM-MIL33C-F
122983
Mechanical interlock, withdrawable units
Type 2, for 2 circuit-breakers: A normal power supply (A) and an
emergency network supply (B). 1 set of cables also required.
IZM20, 32, 40, 63...W
IN20, 32, 40, 63...W
IZM-MIL2C-W
122985
1 off
Type 31, for 3 circuit-breakers: Two normal power supplies
(A, C) and an emergency network supply (B). When B in Off, A and
C can be switched on. B can be switched on only when A and C are
in Off. Two sets of cables required in addition.
IZM-MIL31C-W
122986
Type 32, for 3 circuit-breakers: Two normal power supplies (A, C)
and a coupling (B). Any one or two circuit-breakers can be closed
at the same time. Three sets of cables are required in addition.
IZM-MIL32C-W
122987
Type 33, for 3 circuit-breakers: Three power supplies (A, B, C),
normal or emergency network. Only one of the three circuit-
breakers can be switched on at any one time. Three sets of cables
are required in addition.
IZM-MIL33C-W
122988
Cable sets for mechanical interlock
Depending on the type of interlock, a particular number of cable connectors is required.
With the flexible cable connectors, various different switch arrangements can be implemented.
Each set contains two cables.
1520 mm long
IZM20, 32, 40, 63...
IN20, 32, 40, 63...
IZM-MIL-CAB1520
122975
1 off
1830 mm long
IZM-MIL-CAB1830
122976
2440 mm long
IZM-MIL-CAB2440
122977
3050 mm long
IZM-MIL-CAB3050
122978
Instruction
For possible switching states, ￫Page 77
IZM-MIL...
HPL18069EN
