Voltage releases
A closing release can be combined with a shunt release and an undervoltage
release or with a second shunt release. (DF: 100%). Suited for uninterrupted
operation, which ensures electrical interlocking in Off position.
Shunt release
24 DC IZM20, 32, 40, 63...
IN20, 32,40, 63...
IZM-ST24DC
122934
1 off If ordered separately a secondary
terminal block IZM‐SEC… is
necessary for connection. Order
separately if required. For terminal
assignment, see page 77
24 DC +IZM-ST24DC
122736
48 DC IZM-ST48DC
122935
48 DC +IZM-ST48DC
122737
60 DC IZM-ST60DC
122930
60 DC +IZM-ST60DC
123914
110 - 125 DC
110 - 127 AC
IZM-ST110AD
122936
110 - 125 DC
110 - 127 AC
+IZM-ST110AD
122738
220 - 250 DC
208 - 240 AC
IZM-ST230AD
122937
220 - 250 DC
208 - 240 AC
+IZM-ST230AD
122739
2nd shunt release
Can not be combined with an undervoltage release.
24 DC IZM20, 32, 40, 63...
IN20, 32,40, 63...
+IZM-STS24DC
122740
1 off If ordered separately a secondary
terminal block IZM‐SEC… is
necessary for connection. Order
separately if required. For terminal
assignment, see page 77
48 DC +IZM-STS48DC
122741
60 DC +IZM-STS60DC
123922
110 - 127 DC
110 - 127 AC
+IZM-STS110AD
122742
208 - 250 DC
208 - 250 AC
+IZM-STS230AD
122743
Closing releases
24 DC IZM20, 32, 40, 63...
IN20, 32,40, 63...
IZM-SR24DC
122942
1 off If ordered separately a secondary
terminal block IZM‐SEC… is
necessary for connection. Order
separately if required. For terminal
assignment, see page 77
24 DC +IZM-SR24DC
122744
48 DC IZM-SR48DC
122943
48 DC +IZM-SR48DC
122745
60 VDC IZM-SR60DC
123954
60 VDC +IZM-SR60DC
123938
110 - 125 DC
110 - 127 AC
IZM-SR110AD
122944
110 - 125 DC
110 - 127 AC
+IZM-SR110AD
122746
220 - 250 DC
208 - 240 AC
IZM-SR230AD
122945
220 - 250 DC
208 - 240 AC
+IZM-SR230AD
122747
IZM-ST..., IZM-SR... HPL18065EN
