IZM circuit-breakers, IN switch-disconnectors
Accessories for IZMX16
2010 CA08103002Z-EN
18/15
Rated control
voltage
For use with Part no.
Article no.
Part no. suffix
“+IZM...”
Article no. for
ordering with basic
device
Price
See price
list
Std.
pack
Notes
Us
V
Voltage releases
Latch check switch, 1 changeover contact
– IZMX16…
INX16…
IZMX-LCS16
123885
1 off For external application
– +IZMX-LCS16
123884
– IZMX-LCS16-SR
123887
For use with closing release
IZMX16-SR...
– +IZMX-LCS16-SR
123886
Under voltage release
Cannot be combined with a second voltage release.
24 DC IZMX16…
INX16…
IZMX-UVR24DC
123744
1 off An additional control circuit
terminal block is required for
retrofitting. ￫Page 18/19
+IZMX-UVR24DC
123743
48 DC IZMX-UVR48DC
123748
+IZMX-UVR48DC
123747
110 - 125 DC
110 - 127 AC
IZMX-UVR110AD
123801
+IZMX-UVR110AD
123761
220 - 250 DC
208 - 240 AC
IZMX-UVR220AD
123873
+IZMX-UVR220AD
123841
Auxiliary contacts
Standard auxiliary switch for On-Off signaling
The basic device already contains two changeover contacts.
Two additional changeover contacts possible.
– IZMX16…
INX16…
IZMX-AS22
123881
1 off Three additional control
circuit terminal blocks are
required for retrofitting.
￫Page 18/19
+IZMX-AS22
123880
IZMX-UVR..., IZMX-AS22 HPL18015EN
