18/16 IZM circuit-breakers, IN switch-disconnectors
Accessories for IZMX16
2010 CA08103002Z-EN
For use with Part no.
Article no.
Part no. suffix “+IZM...”
Article No. for ordering
with basic device
Price
See price
list
Std. pack Notes
Trip indication and reset options
Trip-indicating auxiliary switch
Overcurrent trip switch (OTS) with two changeover
contacts.
IZMX16… IZMX-OTS
123889
1 off Three additional control circuit
terminal blocks are required for
retrofitting.
+IZMX-OTS
123888
Automatic reset
The switch can be switched on again immediately after a
trip. The switch does not contain the mechanical trip-indi-
cator (red pin). Cannot be combined with remote reset.
IZMX16… IZMX-RA
123898
1 off –
+IZMX-RA
123897
–
Locking facilities
Locking of ON/OFF buttons
Padlockable front cover for On-Off pushbutton.
IZMX16…
INX16…
IZMX-PLPC16
123946
1 off –
+IZMX-PLPC16
123906
–
Key locking in safe Off
The “Safe Off” locking feature prevents switching on.
Neither remote nor local switching on is possible.
IZMX16…
INX16…
IZMX-KLP-SO16-CASTELL
124184
1 off Castell installation kit without lock
cylinder.
IZMX-KLP-SO16-RONIS
124186
Ronis installation kit without lock
cylinder.
IZMX-KLP-SO16-KIRK
126481
Kirk installation kit without lock
cylinder.
IZMX-KLP-SO16-CES
126479
CES installation kit without lock
cylinder.
IZMX-OTS, IZMX-RR..., IZMX-RA, IZMX-PLPC16, IZMX-KL... HPL18016EN
