18/14 IZM circuit-breakers, IN switch-disconnectors
Accessories for IZMX16
2010 CA08103002Z-EN
Accessories for IZMX16
Accessories for IZMX16
Rated control
voltage
For use with Part no.
Article no.
Part no. suffix
“+IZM...”
Article no. for ordering
with basic device
Price
See price list
Std.
pack
Notes
Us
V
Switching operations counter
Counts the number of On-Off operations. Can also be installed without
motor operator.
– IZMX16…
INX16…
IZMX-OC16
123606
1 off –
– IZMX16…
INX16…
+IZMX-OC16
123605
1 off –
Voltage releases
A closing release can be combined with a voltage release and an
undervoltage release or with two voltage releases.
Shunt releases
24 DC IZMX16…
INX16…
IZMX-ST24DC
123608
1 off An additional control circuit
terminal block is required for
retrofitting. ￫Page 18/19
+IZMX-ST24DC
123607
48 DC IZMX-ST48DC
123656
+IZMX-ST48DC
123616
110 - 125 DC
110 - 127 AC
IZMX-ST110AD
123728
+IZMX-ST110AD
123696
220 - 250 DC
208 - 240 AC
IZMX-ST230AD
123730
+IZMX-ST230AD
123729
2nd shunt release
Cannot be combined with an undervoltage release.
24 DC IZMX16…
INX16…
+IZMX-STS24DC
123731
1 off An additional control circuit
terminal block is required for
retrofitting. ￫Page 18/19 48 DC +IZMX-STS48DC
123732
110 - 125 DC
110 - 127 AC
+IZMX-STS110AD
123733
220 - 250 DC
208 - 240 AC
+IZMX-STS230AD
123734
Closing releases
without latch check switch
24 DC IZMX16…
INX16…
IZMX-SR24DC
123736
1 off An additional control circuit
terminal block is required for
retrofitting. ￫Page 18/19
+IZMX-SR24DC
123735
48 DC IZMX-SR48DC
123738
+IZMX-SR48DC
123737
110 - 125 DC
110 - 127 AC
IZMX-SR110AD
123740
+IZMX-SR110AD
123739
220 - 250 DC
208 - 240 AC
IZMX-SR230AD
123742
+IZMX-SR230AD
123741
IZMX-OC16, IZMX-ST..., +IZMX-STS..., IZMX-SR.. HPL18014EN
