IZM circuit-breakers, IN switch-disconnectors
Accessories for IZMX16
2010 CA08103002Z-EN
18/17
Rated control
voltage
For use with Part no.
Article no.
Part no. suffix “+IZM...”
Articleno.fororderingwith
basic device
Price
See price
list
Std. pack Notes
Us
V
Options and accessories for trip units
Trip unit for system protection Type A
(Digitrip 520)
– IZMX-DTA
124012
1 off –
Control unit for selective protection – IZMX-DTV
124013
1 off –
Add-on functions for Type Vcircuit-breakers (equipped with Digitrip 520LSI)
Ground fault protection – IZMX16…-V…
(Digitrip 520LSI)
+IZMX-DTV-EP
124016
1 off –
Zone selectivity
Zone selectivity shortens the stagger
times in the range of the delayed
short-circuit protection.
– IZMX16…-V…
(Digitrip 520LSI)
+IZMX-DTV-ZSI
124017
1 off –
Control unit for universal protection – IZMX-DTU
124014
1 off –
Standard for all circuit-breakers Type U:
• Display
• Communication-capability
• Overload alarm signal
Instead of the overload alarm (HLA) either the function
ground-fault protection (EP) or ground-fault alarm (EA) can be selected.
For fieldbus communications a communications module
must be selected in addition.
Add-on functions for circuit-breakers Type U (equipped with Digitrip 520M)
Ground fault protection
With ground-fault protection instead of
overload alarm.
24 DC IZMX16…-U…
(Digitrip 520M)
+IZMX-DTU-EP
124018
1 off 24 V DC control voltage
required
Ground alarm
With ground-fault alarm instead of
overload alarm.
24 DC IZMX16…-U…
(Digitrip 520M)
+IZMX-DTU-EA
124019
1 off
ARMS Function
The ARMS (Arcflash Reduction Mainte-
nance SystemTM) function enhances
personnel safety by reducing the tripping
time through a short-circuit protection
bypass in the event of an arcing fault.
24 DC IZMX16…-U…
(Digitrip 520M)
+IZMX-DTU-ARMS
124020
1 off
Zone selectivity
Zone selectivity decreases the time
delays in time selective coordination.
24 DC IZMX16…-U…
(Digitrip 520M)
+IZMX-DTU-ZSI
124021
1 off
Communication modules
Communication module
Modbus
– IZMX16… IZMX-MCAM
122892
1 off When retrofitting,
four additional control
circuit terminal blocks
are required.
￫Page 18/19
Communication module
PROFIBUS
– IZMX16… IZMX-PCAM
122913
1 off
Test device
Hand-held tester for Digitrip
Hand-held tester (100 - 240 V AC)
– IZMX16...
IZM26...
IZM-TEST-KIT
124161
1 off –
IZMX-DTA, IZMX-DTV..., IZMX-DTU..., IZM-TEST, IZMX-M(P)CAM... HPL18017EN
