IZM circuit-breakers, IN switch-disconnectors
Accessories for IZMX16
2010 CA08103002Z-EN
18/13
Accessories for IZMX16
Rated
operational
current
Rated
ultimate
short-circuit
breaking
capacity
Pole For use with Part no.
Article no.
Part no. suffix “+IZM...”
Article no. for ordering
with basic device
Price
See price
list
Std.
pack
Notes
In Icu
A kA
Withdrawable units
Cassettes
Equipment supplied: arcing chamber cover, coding to basic device
≦ 1600 ≦ 65 3 IZMX16…3-...W
INX16…3-...W
IZMX-CAS163-1600
101537
1 off Without control circuit
terminals
+IZMX-CAS163-1600
101536
With control circuit
terminals according to
ordered options
IZMX-CAS163-1600-SEC
123986
Fully equipped with
control circuit terminals
≦ 1600 ≦ 65 4 IZMX16…4-...W
INX16…4-...W
IZMX-CAS164-1600
101539
Without control circuit
terminals
+IZMX-CAS164-1600
101538
With control circuit
terminals according to
ordered options
IZMX-CAS164-1600-SEC
124175
Fully equipped with
control circuit terminals
Shutter protection against direct contact
When the switch is withdrawn from its connected position, the shutters automatically
cover the cassette’s live main terminals.
800 - 1600 – 3 (+)IZMX-CAS163… IZMX-SH163
101542
1 off –
+IZMX-SH163
101541
4 (+)IZMX-CAS164… IZMX-SH164
101544
+IZMX-SH164
101543
Rated control
voltage
For use with Part no.
Article no.
Part no. suffix
“+IZM...”
Article no. for order-
ing with basic device
Price
See price
list
Std. pack Notes
Us
V
Motor operator
The motor automatically tensions the spring-operated stored energy mechanism for
remote or local actuation. A signaling switch for the “Spring-operated stored energy
mechanism tensioned” message is included as standard.
24 DC IZMX16…
INX16…
IZMX-M16-24DC
123594
1 off For retrofitting, two
additional control circuit
terminal blocks are
required.
￫Page 18/19
24 DC IZMX16…
INX16…
+IZMX-M16-24DC
123593
48 DC IZMX16…
INX16…
IZMX-M16-48DC
123596
48 DC IZMX16…
INX16…
+IZMX-M16-48DC
123595
110 - 125 DC IZMX16…
INX16…
IZMX-M16-110DC
123598
110 - 125 DC IZMX16…
INX16…
+IZMX-M16-110DC
123597
220 - 250 DC IZMX16…
INX16…
IZMX-M16-220DC
123600
220 - 250 DC IZMX16…
INX16…
+IZMX-M16-220DC
123599
110 - 127 AC IZMX16…
INX16…
IZMX-M16-110AC
123602
110 - 127 AC IZMX16…
INX16…
+IZMX-M16-110AC
123601
220 - 240 AC IZMX16…
INX16…
IZMX-M16-230AC
123604
220 - 240 AC IZMX16…
INX16…
+IZMX-M16-230AC
123603
IZMX-CAS..., IZMX-SH..., IZMX-M16... HPL18013EN
