18/10 IZM circuit-breakers, IN switch-disconnectors
Compact air circuit-breakers, 3 and 4 pole
2010 CA08103002Z-EN
www.eaton.comCompactaircircuit-breakers, 3and 4pole
Fixed
Withdrawable
Switching
capacity
Rated
operational
current
Setting range
Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Std. pack
Overload
releases
Short-circuit releases
Delayed
Non-delayed
Cassette must be
ordered separately.
I
cu
/I
cs
I
n
= I
u
I
r
I
sd
= I
r
x … I
i
= I
n
x …
kA/kA
A
A
3 pole ircuit-breaker for selective protection
Main terminals must be separately ordered.
42/42
630
315 – 630
2 - 10
2 - 12, OFF
IZMX16B3-V06F
123346
IZMX16B3-V06W
122851
1 off
800
400 – 800
IZMX16B3-V08F
123347
IZMX16B3-V08W
122918
1000
500 – 1000
IZMX16B3-V10F
123348
IZMX16B3-V10W
122920
1250
625 – 1250
IZMX16B3-V12F
123349
IZMX16B3-V12W
122922
1600
800 – 1600
IZMX16B3-V16F
123350
IZMX16B3-V16W
122924
50/50
630
315 – 630
IZMX16N3-V06F
123371
IZMX16N3-V06W
123097
800
400 – 800
IZMX16N3-V08F
123372
IZMX16N3-V08W
123099
1000
500 – 1000
IZMX16N3-V10F
123373
IZMX16N3-V10W
123101
1250
625 – 1250
IZMX16N3-V12F
123374
IZMX16N3-V12W
123103
1600
800 – 1600
IZMX16N3-V16F
123375
IZMX16N3-V16W
123106
65/50
630
315 – 630
IZMX16H3-V06F
123396
IZMX16H3-V06W
123146
800
400 – 800
IZMX16H3-V08F
123397
IZMX16H3-V08W
123147
1000
500 – 1000
IZMX16H3-V10F
123398
IZMX16H3-V10W
123148
1250
625 – 1250
IZMX16H3-V12F
123399
IZMX16H3-V12W
123149
1600
800 – 1600
IZMX16H3-V16F
123405
IZMX16H3-V16W
123150
4 pole circuit-breakers for universal protection (Digitrip 520 M)
Main terminals must be separately ordered.
42/42
630
315 – 630
2 - 10
2 - 12, OFF
IZMX16B4-V06F
123471
IZMX16B4-V06W
123221
1 off
800
400 – 800
IZMX16B4-V08F
123472
IZMX16B4-V08W
123222
1000
500 – 1000
IZMX16B4-V10F
123473
IZMX16B4-V10W
123223
1250
625 – 1250
IZMX16B4-V12F
123474
IZMX16B4-V12W
123224
1600
800 – 1600
IZMX16B4-V16F
123475
IZMX16B4-V16W
123225
50/50
630
315 – 630
IZMX16N4-V06F
123496
IZMX16N4-V06W
123246
800
400 – 800
IZMX16N4-V08F
123497
IZMX16N4-V08W
123247
1000
500 – 1000
IZMX16N4-V10F
123498
IZMX16N4-V10W
123248
1250
625 – 1250
IZMX16N4-V12F
123499
IZMX16N4-V12W
123249
1600
800 – 1600
IZMX16N4-V16F
123500
IZMX16N4-V16W
123250
65/50
630
315 – 630
IZMX16H4-V06F
123531
IZMX16H4-V06W
123271
800
400 – 800
IZMX16H4-V08F
123537
IZMX16H4-V08W
123272
1000
500 – 1000
IZMX16H4-V10F
123543
IZMX16H4-V10W
123273
1250
625 – 1250
IZMX16H4-V12F
123549
IZMX16H4-V12W
123274
1600
800 – 1600
IZMX16H4-V16F
123555
IZMX16H4-V16W
123275
