IZM circuit-breakers, IN switch-disconnectors
IZMX16 circuit-breakers
2010 CA08103002Z-EN
18/5
Key to type references
IZM X16 B 3 - A 06 W
IN N 4 V 08 F
H U 10
12
16
IZM, IN = Product family
Frame size
X16: Compact ACB, 630 - 1600 A
Switching capacity
B = Basic
N = Normal
H = High
Number of poles
3: 3 pole
4: 4 pole
Trip type
A = System protection =
Digitrip 520 LI
V = Selective trip =
Digitrip 520 LSI(G)
U = Universal protection =
Digitrip 520MC LSI(G)
Rated operational current
06: 630 A
08: 800 A
10: 1000 A
12: 1250 A
16: 1600 A
Model
W = Withdrawable units
F = Fixed mounted
IZMX16 circuit-breakers 1
￫Page 18/10
Main terminal kits 2
Universal terminals
3- and 4 pole,
horizontal/vertical
￫Page 18/19
Cassette for
withdrawable units 3
Cassettes 1600 A
With and without control
circuit terminals
￫Page 18/13
Control circuit terminal
units 4
Either 8, 20 or 30 units
￫Page 18/19
Auxiliary contacts 5
Signalling switch ON-OFF
￫Page 18/15
Motor operator 6
Automatic charging of the
stored energy mechanism
for remote or local
operations
￫Page 18/13
Switching operations
counters 7
￫Page 18/14
Door escutcheon 8
￫Page 18/76
Trip unit (Digitrip 520M) 9
Type A circuit-breakers
Type V circuit-breakers
Type U circuit-breakers
￫Page 18/17
Undervoltage releases 10
￫Page 18/15
Shunt releases 11
￫Page 18/14
Communication
modules 12
PROFIBUS-DP, Modbus
￫Page 18/8
￫Page 18/17
￫Page 18/71
￫Page 18/118
Trip indication switches 13
Overload trip switch
(OTS), 2 C
￫Page 18/16
Closing releases 14
￫Page 18/14
