Circuit-breakers, switch-disconnectors
Accessories, earth-fault release
2010 CA08103002Z-EN
17/135
Accessories,earth-fault release
Earth-fault release
For use with Part no.
Article no. when
ordered separately
Price
See price
list
Std. pack Notes
Cover for 4th pole
Additional shroud for
mounting the NZM2-XR...
and NZM3-XR... on a 4 pole
switch
NZM2-4
N2-4
NZM2-XAVPR
266677
1 off –
NZM3-4
N3-4
NZM3-XAVPR
266678
1 off
Sealing device for "Auto" position
Manual operation possible
only after removing seal
NZM2(-4)
N(S)2(-4)
NZM2-XRDPL
137305
1 off Suitable for remote operator NZM2-XRD
Protective cover for door cutout
NZM2-XR
NZM3-XR
NZM4-XR
RTR-NZM10
034825
1 off Electrical remote switching and manual tripping (push to trip) are still
possible.
High switching capacity
150 kA; 415 V 50/60 Hz
Number of
poles
Rated current = Rated
uninterrupted current
Setting range Part no.
Article no.
Price
See price
list
Std. pack
Overload
releases
Short-circuit
releases
Iu Ir Ii B = box terminals
S = screw terminals A A A
Circuit-breakers with earth-fault release, 3 pole
For apparatus with power electronics,
such as power inverters and frequency inverters
AC/DC sensitive according to core-balance principle in range of 0 – 100 kHz residual-current frequency.
Not UL/CSA approved.
Suitable for use in three-phase systems.
Rated operating voltage: 400 V (50/60 Hz)
Rated fault current IΔn = 0.03 A
Internal power supply Ue = 50 - 400 V
Turnkey combination of current-limiting circuit-breaker and residual-current device.
Adjusting buttons can be sealed.
3 pole 125 100-125 750…1250 NZMH2-A125-FIA30
129710
S 1 off
160 125-160 960…1600 NZMH2-A160-FIA30
112627
S
200 160-200 1200…2000 NZMH2-A200-FIA30
112628
S
250 200-250 1500…2500 NZMH2-A250-FIA30
112629
S
125 100-125 750…1250 NZMH2-A125-FIA30-BT
129711
B
160 125-160 960…1600 NZMH2-A160-FIA30-BT
116304
B
200 160-200 1200…2000 NZMH2-A200-FIA30-BT
116305
B
250 200-250 1500…2500 NZMH2-A250-FIA30-BT
116306
B
Notes Notes about terminals￫Page 17/86
I
NZM2, NZM3, NZM4, NZM...FI HPL17135EN
