www.eaton.comCircuit-breakers, switch-disconnectors
Multi-function component adapterss
Part no.
Article no. for separate
order
Price
See price
list
Std. pack
Notes
Information relevant for export to
North America
NZM1-XAD160
104554
1 off
For switch and standard connection with box terminal.
Connection to the system at top using supplied connection
cable.
In conjunction with IP2X protection against contact with a
finger.
Enhanced contact protection on the switch secondary side.
Clips onto busbar with combination foot.
Combination foot for adjustment to 5 and 10 mm rail
thickness , terminal capacity 6 x 9 x 0.8.
Rated short-circuit switching capacity 35 kA at 480 V.
Mounted by latching onto de-energized busbar.
Product Standards UL508A;
CSA-C22.2 No. 14; IEC 60439-1;
CE marking
UL File No.
E300273
UL CCN
NMTR, NMTR7
CSA File No.
236217
CSA Class No.
3211-37
NA Certification
UL Listed, CSA certified
Conditions of Acceptability
Refer to approbation report
Suitable for
Feeder circuits
Max. Voltage Rating 600 V AC
Degree of Protection Feeder circuits
NZM2-XAD250
104555
Connection to the system possible at top or bottom via
connection on rear (+)NZM2-XKR4…
Mounting using clamp and screw fixing.
Rated short-circuit switching capacity 65 kA at 480 V, 50 kA
at 600 V.
Mounted by latching onto de-energized busbar.
NZM3-XAD630
107206
Connection to the system possible at top or bottom via
connection on rear (+)NZM3-XKR13…
For mounting use claw terminal.
Rated short-circuit switching capacity 65 kA at 480 V, 50 kA
at 600 V.
Mounted by latching onto de-energized busbar.
NZM2-4-XAD250
138388
Connection to the system possible at top via connection on
rear with (+)NZM2-4-XKR4…
Mounting using clamp and screw fixing.
NZM3-4-XAD630
138389
Connection to the system possible at top via connection on
rear with (+)NZM3-4-XKR13…
Mounting using clamp and screw fixing.
NZM2-XKR4
281666
1 off
Part no. and part no. suffix include parts for one switch side
at top or bottom (for NZM3 top only).
Required with component adapter and switch with
connection on rear.
Product Standards
UL 489; CSA-C22.2
No. 5-09; IEC 60947-2;
CE marking
UL File No.
E31593
UL CCN
DIVQ
CSA File No.
022086
CSA Class No.
1432-01
NA Certification
UL Listed, CSA certified
Specially designed for NA Yes
Suitable for
Feeder circuits, branch
circuits
Current Limiting CB
Yes
Max. Voltage Rating
480Y/277 V
Degree of Protection
IEC: IP20; UL/CSA Type: -
–
NZM3-XKR13
281668
–
NZM2-4-XKR4
118907
–
NZM3-4-XKR13
119020
–
