17/140 Circuit-breakers, switch-disconnectors
Diagnostics, communication
2010 CA08103002Z-EN
Diagnostics,communication
Description Part no.
Article no.
Price
See price list
Std. pack Notes
FDT frame software for operating field devices
PC software for integration of software modules (DTM's)
according to the FDT standard V1.2 (e.g. NZM-XPC-DTM).
• Operation of a temporary or stationary service station for
engineering, remote diagnostics, remote operation and
remote parameter definition of networked switchgear and
field devices.
• Engineering of the network topology of networked field
devices.
• Overview representation of the topology with online
status information.
• Access to the device-specific DTM's for configuration,
operation, parameterization and diagnostics of the
devices.
• Storage of all engineering information in a central
database. Download and upload from/to the devices.
FDT-NAVIGATOR
281623
1 off The connection of the field
devices can be implemented
via the PROFIBUS DPV1
master or via gateways (e.g.:
USB/PROFIBUS, Ethernet/
PROFIBUS).
Communication interfacing
for the PC and a
communication DTM (driver)
is necessary for this purpose.
DTM software module to FTD standard
PC software module (Device Type Manager) to FDT/DTM
standard V1.2 for integration in the FDT navigator or other
FDT-capable framework software packages (primary
control system, PLC engineering systems).
• Remote diagnostics, remote monitoring, remote
parameter definition and remote operation of the new
NZM2,3,4 circuit-breakers with electronic trip release via
PROFIBUS-DPV1.
• Indication of the circuit-breaker state (on/off/tripped), the
phase currents, parameter data, status data and
diagnostics data.
• Definition of the trip parameters.
• Display and setting the DMI motor starter functions and
assignment of the DMI inputs and outputs.
• Control of the motor starter functions.
NZM-XPC-DTM
281624
1 off For connection of the circuit-
breaker to the PROFIBUS-DP
fieldbus, the accessory
device NZM-XDMI612 and
the fieldbus interface
NZM-XDMI-DPV1 are
required.
NZM interface module to SmartWire-Darwin
The module implements the data connection between the
NZM2/3/4 with electronic release and SmartWire-Darwin.
The following data is transmitted:
• Digital status data (ON/OFF/Tripped)
• Load warnings
• Reason for last trip
• The actual currents
• Switch model
• The current settings of the rotary coding switches
The switch can also be operated with a remote operator.
• Two digital inputs for the switch status
• Two transistor outputs for remote switching
• Retentive memory for energy data (kWh)
Energy data is transmitted through digital input (S0) from an
external energy measuring module NZN...-XMC-SO.
NZM-XSWD-704
135530
1 off A connection cable to the
circuit-breaker and auxiliary
contacts NZM is included as
standard.
