Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

239 / 543

2010 CA08103002Z-EN
Circuit-breakers, switch-disconnectors
Insulated enclosures
Basic
enclosure
Terminals for 3-pole switches fitted by user:
for fourth and fifth conductor (N and PE),
on 4 pole switches: for fifth conductor (PE)
Notes
CI-K5-160-M K10/1, K25/1 Enclosures for separate mounting with top and bottom cable entry, suitable for installation of
circuit-breakers and switch-disconnectors.
Include fixing straps for wall mounting.
Short-circuit resistance at 415 V 50/60 Hz up to 10 kA.
Cannot be used in combination with remote operator NZM...-XR...,
plug-in unit NZM...-XSV or withdrawable unit NZM...-XAV.
Order insulated additional terminal for 4th or 5th pole separately.
Enclosure CI-K5 with hard metric knock-outs
Enclosure CI23 with flanges
CI43, CI45 and CI48 feature gland plates.
Only for switches with box terminals for direct connection of cables.
CI23-150 K10/1, K25/1
CI43-150 K10/1, K25/1, K50/1, K95/1N/BR
CI43-200 K10/1, K25/1, K50/1, K95/1N/BR
CI43-200 K10/1, K25/1, K50/1, K95/1N/BR, K150/1/BR, K240/1/BR
CI45-200 K10/1, K25/1, K50/1, K95/1N/BR, K150/1/BR, K240/1/BR
CI48-250 K95/1N/BR, K150/1/BR, K240/1/BR, K2X240/1/BR
CI-K5-160-M K10/1, K25/1
CI23-150 K10/1, K25/1
CI43-150 K10/1, K25/1, K50/1, K95/1N/BR
CI43-200 K10/1, K25/1, K50/1, K95/1N/BR
CI43-200 K10/1, K25/1, K50/1, K95/1N/BR, K150/1/BR, K240/1/BR
CI45-200 K10/1, K25/1, K50/1, K95/1N/BR, K150/1/BR, K240/1/BR
CI48-250 K95/1N/BR, K150/1/BR, K240/1/BR, K2X240/1/BR
17/143
NZM...-XCI... HPL17143EN
