17/142 Circuit-breakers, switch-disconnectors
Insulated enclosures
2010 CA08103002Z-EN
www.eaton.comInsulatedenclosures
Insulatedenclosures
Degree of
protection
Max. rated
uninterrupted
current
For use with
Part no.
Article no. when
ordered separately
Price
See price
list
Std. pack
I
u
A
Insulated enclosures
With door coupling rotary handle
Complete includes all necessary functional parts
Not UL/CSA approved
Standard, black/grey
Lockable in 0 position on handle with up to 3
padlocks. Additionally with cover interlock.
IP65
≦ 63 A
PN1, N(S)1
NZM1-XCIK5-TVD
271521
1 off
IP65
≦ 63 A
NZM1, PN1, N(S)1
NZM1-XCI23-TVD
271522
1 off
IP64
≦ 125 A
NZM1(-4), PN1(-4),
N(S)1(-4)
NZM1-XCI43-TVD
271523
1 off
IP64
≦ 160 A
NZM1(-4), PN1(-4),
N(S)1(-4)
NZM1-XCI43/2-TVD
104645
1 off
IP64
≦ 200 A
NZM2(-4), PN2(-4),
N(S)2(-4)
NZM2-XCI43-TVD
271524
1 off
IP64
≦ 250 A
NZM2(-4), PN2(-4),
N(S)2(-4)
NZM2-XCI45-TVD
280418
1 off
IP64
≦ 400 A
NZM3(-4), PN3(-4),
N(S)3(-4)
NZM3-XCI48-TVD
271525
1 off
Red-yellow for emergency switching off
Lockable on handle and switch with up to 3
padlocks. Lockable in 0 position on handle.
Additionally with cover interlock and locking
facility on circuit-breaker in 0 position.
IP65
≦ 63 A
PN1, N(S)1
NZM1-XCIK5-TVDVR
271526
1 off
IP65
≦ 63 A
NZM1, PN1, N(S)1
NZM1-XCI23-TVDVR
271527
1 off
IP64
≦ 125 A
NZM1(-4), PN1(-4),
N(S)1(-4)
NZM1-XCI43-TVDVR
271528
1 off
IP64
≦ 160 A
NZM1(-4), PN1(-4),
N(S)1(-4)
NZM1-XCI43/2-TVDVR
104646
1 off
IP64
≦ 200 A
NZM2(-4), PN2(-4),
N(S)2(-4)
NZM2-XCI43-TVDVR
271529
1 off
IP64
≦ 250 A
NZM2(-4), PN2(-4),
N(S)2(-4)
NZM2-XCI45-TVDVR
279356
1 off
IP64
≦ 400 A
NZM3(-4), PN3(-4),
N(S)3(-4)
NZM3-XCI48-TVDVR
271530
1 off
Rated uninterrupted current Terminal capacity
Part no.
Article no. when ordered
separately
Price
See price
list
Std. pack
I
u
A
mm²
Insulated additional terminals
For passing through the neutral and protective conductor
1 pole
32
Flexible, 1 × (1.5 – 6)
K10/1
093827
10 off
63
Flexible, 1 × (6 – 16), stranded, 1 × (16 – 25 )
K25/1
096200
10 off
100
Flexible, 1 × (10 – 35), stranded, 1 × (16 – 50)
K50/1
098573
10 off
160
Stranded, 1 × (16 – 95)
K95/1N/BR
012336
1 off
250
Stranded, 1 × (35 – 150), 2 x (16 – 70)
K150/1/BR
014709
1 off
400
Stranded, 1 × (50 – 240), 2 × (25 – 120)
K240/1/BR
017082
1 off
630
Stranded, 1 × (240 – 300), 2 × (50 – 240)
K2X240/1/BR
019455
1 off
NZM...-XCI...
