14/132 Switched-mode power supply units, power supply units
2010 CA08103002Z-EN
Power supply units GD4
GD4-050-BD3 GD4-100-BD3 GD4-150-BD3 GD4-200-BD3 GD4-300-BD3
General
Protection class 1
Potential isolation Yes, VDE 0551, IEC/EN 60742, SELV
Mains frequency
Rated value Hz 50/60
Range Hz 50…60
Electromagnetic compatibility (EMC)
Emitted interference Class B (EN 55011, 22)
ESD 6 kV contact (Level 3), 8 kV air (Level 3), IEC/EN 61000-4-2
RFI 10 V/m, modulated,
IEC/EN 61000 4-2
Burst 2 kV (Level 3) IEC/EN 61000-4-4
Surge 2 kV (Inst. Class 3), IEC/EN 61000-4-5
Impulse voltage 4.9 kV, IEC EN 60947
Environmental data
Ambient temperature °C -25 - 55
Ambient temperature, storage °C -25 - 85
Pollution degree 2, EN 50178
Vibration 0.075 mm (10 - 57 Hz), 10 cycles, IEC 60068-2-6
Shock resistance, shock duration 11 ms g 15, IEC 60068-2-27 (3 shocks)
Installation altitude m Max. 2000 m a.m.s.l., observe derating above this1)
Protection type IP20
Fixing Screw-on
Mounted position Any
Input voltage
Rated value V AC 400 400 400 400 400
Range V AC Taps ± 5% 380, 400, 420
Rated input current for phase A 0.24 0.46 0.65 0.9 1.8
No-load losses W 5 14.2 13.9 25.5 38.2
Short-circuit losses W 19.6 28.6 44.2 59 55.5
Output voltage
Rated value V DC 24 24 24 24 24
Tolerance
Tolerance See current/voltage characteristic
– – – – –
Ripple % ≦ 3 ≦ 3 ≦ 3 ≦ 3 ≦ 3
Output current (rated value) A 5 10 15 20 30
Output current range at 55 °C A 0 - 5 0 - 10 0 - 15 0 - 20 0 - 30
Terminal capacity
Solid mm2 0.5 - 4 0.5 - 4 0.5 - 4 0.5 - 4 0.5 - 4
Flexible with ferrule mm2 0.5 - 2.5 0.5 - 2.5 0.5 - 2.5 0.5 - 2.5 0.5 - 2.5
Connections Screw terminals Screw terminals Screw terminals Screw terminals Screw terminals
Dimensions
Width mm 125 155 155 190 190
Height mm 73 82 97 105 115
Depth mm 140 170 170 225 240
Weight kg 2.4 4.4 5.8 7.6 11.2
Protection
Input voltage u1 V 3 x 400 3 x 400 3 x 400 3 x 400 3 x 400
Input current I1 A 0.24 0.46 0.65 0.9 1.8
Circuit-breaker
PKZ PKZM0-0,25 PKZM0-0,63 PKZM0-1 PKZM0-1 PKZM0-2,5
Current setting A 0.24 0.46 0.65 0.9 1.8
Miniature circuit-breaker (MCB)
FAZ FAZ-S1/1 FAZ-S1/1 FAZ-S1/1 FAZ-S1/1 FAZ-S2/1
Short-circuit protection only ● ● – – –
Notes 1) Derating
From +44 to +55 °C: linear derating
from 100 % to 93 %
