Automation products
2010 CA08103002Z-EN
Mains power supply units 14/131
Mainspower supplyunitsOrdering
Rated input voltage 50/60 Hz Rated output voltage
(residual ripple)
Input voltage
range
Rated output current Part no.
Article no.
Price
See
price list
Std. pack
V AC V DC V A
Power supply units GW4, GD4
Unregulated, smoothed
Single-phase 230 24 (± 5 %) – 3 GW4-030-BA3
200016
1 off
230 24 (± 5 %) – 5 GW4-050-BA3
200017
230 24 (± 5 %) – 8 GW4-080-BA3
200018
230 24 (± 5 %) – 10 GW4-100-BA3
200019
Three-phase 400 (± 5 %) 24 (± 3 %) – 5 GD4-050-BD3
200007
400 (± 5 %) 24 (± 3 %) – 10 GD4-100-BD3
200009
400 (± 5 %) 24 (± 3 %) – 15 GD4-150-BD3
200011
400 (± 5 %) 24 (± 3 %) – 20 GD4-200-BD3
200012
400 (± 5 %) 24 (± 3 %) – 30 GD4-300-BD3
200014
Switched-mode power supply units SN3
Primary switched-mode power supply unit, power reserve of up to 50 %,
Up to 5 devices can be connected in parallel increase power and for redundancy
110 - 240 AC 24 V DC (fixed)
(20 MHz normally < 50 mVss)
85 - 264 AC
100 - 350 DC1)
5 SN3-050-BU8
100640
1 off
110 - 120 AC
220 - 240 AC
24 V DC (fixed)
(20 MHz normally < 50 mVss)
85 - 132 AC
184 - 264 AC
220 - 350 DC1)
10 SN3-100-BV8
100641
110 - 120 AC
220 - 240 AC
24 V DC (fixed)
(20 MHz normally < 50 mVss)
85 - 132 AC
184 - 264 AC
220 - 350 DC1)
20 SN3-200-BV8
100642
110 - 240 AC/DC 22 - 28 V DC (adjustable)
(20 MHz normally < 50 mVss)
85 - 264 AC
100 - 350 DC1) 5 SN3-050-EU8
100643
110 - 240 AC/DC 22 - 28 V DC (adjustable)
(20 MHz normally < 50 mVss)
85 - 264 AC
100 - 350 DC1)
10 SN3-100-EU8
100644
110 - 240 AC/DC 22 - 28 V DC (adjustable)
(20 MHz normally < 50 mVss)
85 - 264 AC
100 - 350 DC1) 20 SN3-200-EU8
100645
Switched-mode power supply units easyPOW
Primary-switched mode, regulated
100 - 240 24/12 – 0.35
0.02
EASY200-POW
229424
1 off
100 - 240 24 (± 3%) – 1.25 EASY400-POW
212319
100 - 240 24 (± 3%) – 1.25 EASY430-POW
110940
100 - 240 24 (± 3%) – 2.5 EASY500-POW
110941
100 - 240 24 (± 3%) – 4.2 EASY600-POW
262399
Signal module for power supply units SN3-...-EU8
LED display: Input OK
LED display: Output OK
LED display: Remote off
Relay output 1 changeover: Input OK
Relay output 1 changeover: Output OK
Remote On/Off function for external switching
For use with
SN3-50-EU8
SN3-100-EU8
SN3-200-EU8
SN3-000-MMEU8
100646
1 off
Notes 1) At U ≧ 264 V DC, use suitable external fuse in addition
2) For UL/CSA information, technical data and dimensions see Chapter 12.
