Remote I/OEC4E,SWDExpansionmodules,accessories
Inputs
Outputs
Supply
voltage
connection
Part no.
Article no.
Price
See
price list
Std. pack
Information relevant for export to
North America
Digital
Analog Of which
usable as
digital
Relay
10
A
(
UL)
Tran-
sistor
Analog
I/O expansion modules
Can be used through CANopen for: XC100/200, EC4P, MFD4
6
–
–
4
–
–
24
V DC
EC4E-221-6D4R1
114296
1
off
NA Certification
Requestfiled
for UL and
CSA
Degree of Protection IEC: IP20, UL/
CSA Type: -
6
–
–
–
4
–
24
V DC
EC4E-221-6D4T1
114297
1
off
Notes
Technical data for the EASY...expansion units￫Chapter 12
SWD gateways
Gateway for connecting to the fieldbus and for supplying the SmartWire-Darwin (SWD)
slaves and switchgear.
Connection to PROFIBUS-DP as slave.
Automatic baud rate detection from 9.6 kbit/s to 12 Mbit/s.
Address range 1 - 126.
D-sub 9-pin socket.
Connection of up to 58 SWD slaves.
EU5C-SWD-DP
116308
1
off
NA Certification
Requestfiled
for UL and
CSA
Connection to CANopen as slave.
Automatic baud rate detection from 10 kbit/s to 1 Mbit/s.
Address range 1 - 32.
D-sub 9-pin plug.
Connection of up to 99 SWD slaves.
EU5C-SWD-CAN
116307
SWD I/O modules
SmartWire-Darwin slaves for the connecting digital I/O.
Digital module with 8 digital inputs 24 V DC
EU5E-SWD-8DX
116381
1
off
NA Certification
Requestfiled
for UL and
CSA
Digital module with 4 digital inputs 24 V DC and 4 transistor outputs
24
V DC/0.5 A
EU5E-SWD-
4
D4D
116382
Digital module with 4 digital inputs 24 V DC and 2 relay outputs
250
V AC
EU5E-SWD-
4
D2R
116383
Coding elements
Included as standard with every
electronics module.
Prevents incorrect connection of the
electronics modules.
For use with
XN-...DI-24VDC…
XN-KO/2
140114
1
off
UL/CSA certification not required
XN-2DI-120/230VAC
XN-KO/5
140117
XN-xDO-24VDC…
XN-KO/6
140118
XN-2DO-R-NO
XN-KO/8
140119
XN-2DO-R-NC
XN-KO/9
140120
XN-2DO-R-CO
XN-KO/10
140121
XN-1AI-I(0/4…20MA)
XN-2AI-I(0/4…20MA)
XN-KO/11
140122
XN-1AI-U(-10/0...+10VDC)
XN-2AI-U(-10/0...+10VDC)
XN-2AI-Pt/Ni-2/3
XN-2AI-THERMO-PI
XN-4AI-U/I
XN-KO/12
140123
XN-1AO-I(0/4...20MA)
XN-2AO-I(0/4...20MA)
XN-KO/13
140124
XN-2AO-U(-10/0...+10VDC)
XN-KO/14
140125
XN-1CNT-24VDC
XN-1RS232
XN-1RS485/422
XN-1SSI
XN-KO/15
140126
XN-BR-24VDC-D
XN-PF-24VDC-D
XN-KO/16
140127
XN-PF-120/230VAC-D
XN-KO/17
140128
