Automation products
Basic modules
2010 CA08103002Z-EN
Remote I/O XI/ON 14/95
• 4 connection levels
Block modules Connection to
C rail
XN-16DI-24VDC-P XN-B4T-SBBC
140135
1 off Product Standards UL 508; cUL;
IEC/EN 6113-2;
CE marking
UL File No. E205091
UL CCN NRAQ, NRAQ7
CSA File No. UL report applies to
both US and Canada
CSA Class No. -
NA Certification UL Recognized,
certified by UL for use
in Canada
Degree of Protection IEC: IP20, UL/CSA
Type: - • 6 connection levels
Slice modules – XN-4DI-24VDC-P
XN-4DI-24VDC-N
XN-S6T-SBBSBB
140082
1 off
Connection to
C rail
XN-4DO-24VDC-0.5A-P
XN-4AI-U/I
XN-S6T-SBCSBC
140083
Block modules – XN-32DI-24VDC-P XN-B6T-SBBSBB
140136
Connection to
C rail
XN-32DO-24VDC-0.5A-P XN-B6T-SBCSBC
140159
Screw terminals
• 3 connection levels
Slice modules Base module for field
power supply
Base module for the
gateway supply (with
XN-BR-24VDC-D)
XN-BR-24VDC-D
XN-PF-24VDC-D
XN-PF-120/230VAC-D
XN-P3S-SBB
140085
1 off Product Standards UL 508; cUL;
IEC/EN 6113-2;
CE marking
UL File No. E205091
UL CCN NRAQ, NRAQ7
CSA File No. UL report applies to
both US and Canada
CSA Class No. -
NA Certification UL Recognized,
certified by UL for use
in Canada
Degree of Protection IEC: IP20, UL/CSA
Type: -
– XN-2DI-24VDC-P
XN-2DI-24VDC-N
XN-2DI-120/230VAC
XN-1AI-...
XN-2AI-I(0/4...20MA)
XN-2AI-U(-10/0...+10VDC)
XN-2AI-Pt/Ni-2/3
XN-1AO-I(0/4...20MA)
XN-2AO-...
XN-S3S-SBB
140088
Connection to C rail XN-2DO-24VDC-...
XN-2DO-120/230VAC-0.5A
XN-S3S-SBC
140090
Block modules – XN-16DI-24VDC-P XN-B3S-SBB
140137
Connection to C rail XN-16DO-24VDC-0.5A-P XN-B3S-SBC
140138
• 4 connection levels
Slice modules Base module for field
power supply
Base module for the
gateway supply (with
XN-BR-24VDC-D)
Connection to
C rail
XN-BR-24VDC-D
XN-PF-24VDC-D
XN-PF-120/230VAC-D
XN-P4S-SBBC
140087
1 off
Description For use with Part no.
Article no.
Price
See
price
list
Std. pack Information relevant for export to
North America
HPL14095EN
