Automation products

Digital input modules

2010

CA08103002Z-EN

Remote I/O XI/ON

Remote I/OXI/ONDigital inputmodules

Digital input modules

XN-S3…-SBB for XN-2DI-24VDC-P

XN-S4…-SBBC for XN-2DI-24VDC-P

XN-S3…-SBB for XN-2DI-24VDC-N

XN-S4…-SBBC for XN-2DI-24VDC-N

XN-S3…-SBB for XN-2DI-120/230VAC

XN-S4…-SBBC for XN-2DI-120/230VAC
