Automation products

Analog input modules

2010

CA08103002Z-EN

Remote I/O XI/ON

14/105

Remote I/OXI/ONAnalog inputmodules

Analog input modules

XN-S3…-SBB for XN-1AI-I(0/4...20MA)

XN-S3…-SBB for XN-1AI-U(-10/0...+10VDC)

Analog sensor/transmitter, without transmitter supply

XN-S4…-SBBS for XN-1AI-I(0/4...20MA)

XN-S4…-SBBS for XN-1AI-U(-10/0...+10VDC)

Analog transmitter with non-isolated transmitter supply

XN-S3…-SBB for XN-2AI-I(0/4...20MA), XN-2AI-U(-10/0...+10VDC)

Analog sensor/transmitter, without transmitter supply

XN-S4…-SBBS for XN-2AI-I(0/4...20MA), XN-2AI-U(-10/0...+10VDC),

Analog transmitter with non-isolated transmitter supply

XN-S4...-SBBS for XN-2AI-I(0/4...20MA)

Two-conductor connection without external transmitter supply

11 21

12 22

13 23

Sh

11 21

12 22

13 23

14 24

Sh

U

h

U

h

+

11 21

12 22

13 23

Sh

Sh

11 21

12 22

13 23

14 24

Sh

Sh

U

h

+

U

h

+

11 21

12 22

13 23

14 24
