Automation products
Digital output modules
2010 CA08103002Z-EN
Remote I/O XI/ON 14/103
Remote I/OXI/ONDigitaloutputmodules
Digital output modules
XN-S3…-SBC for
XN-2DO-24VDC-0.5A-P
XN-2DO-24VDC-2A-P
XN-S4…-SBCS for
XN-2DO-24VDC-0.5A-P
XN-2DO-24VDC-2A-P
XN-S3…-SBC for XN-2DO-24VDC-0.5A-N XN-S4…-SBCS for XN-2DO-24VDC-0.5A-N
XN-S3…-SBC for XN-2DO-120/230VAC-0.5A XN-S4…-SBCS for XN-2DO-120/230VAC-0.5A
XN-S4…-SBCS for XN-4DO-24VDC-0.5A-P XN-B3…-SBC for XN-16DO-24VDC-0.5A-P
