Remote I/O XI/ON
Remote I/OXI/ONI/Omodules
Description For use with Part no.
Article no.
Price
See
price list
Std. pack
Analog input modules
Slice modules XN 1 analog input
0/4 to 20 mA
XN-S3T-SBB
XN-S3S-SBB
XN-S4T-SBBS
XN-S4S-SBBS
XN-1AI-I(0/4...20MA)1)
140063
1 off
2 analog inputs
0/4 to 20 mA
XN-2AI-I(0/4...20MA)1)
140144
1 analog input
-10/0 to +10 V DC
XN-1AI-U(-10/0...+10VDC)1)
140064
2 analog inputs
-10/0 to +10 V DC
XN-2AI-U(-10/0...+10VDC)1)
140145
2 analog inputs
Reading of standardized signals for temperature
measurement
Connection of RTDs Pt100, Pt200, Pt500, Pt1000, Ni100,
Ni1000, and Ni1000TK5000 in 2- or 3-wire circuit
XN-2AI-Pt/Ni-2/31)
140067
2 analog inputs
Acquisition of normalized signals for measuring tem-
peratures or voltages up to ± 1 V
Connection of thermocouples of types B, E,
J, K, N, R, S, T
XN-S4T-SBBS-CJ
XN-S4S-SBBS-CJ
XN-2AI-THERMO-PI1)
140068
4 analog inputs
-10/0 to +10 V DC,
0/4 to 20 mA
Selectable for channel
XN-S6T-SBCSBC
XN-S6S-SBCSBC
XN-4AI-U/I1)
140158
Slice modules XNE 8 analog inputs U/I or 4 analog inputs Pt/Ni
-10/0 to +10 V DC, 0/4 to 20 mA
Reading of standardized signals for temperature
measurement
Connection of RTDs Pt100, Pt200, Pt500, Pt1000, Ni100,
Ni1000, and Ni1000TK5000, Ni1000TK5000 in 2- or
3-wire circuit
Selectable for channel
– XNE-8AI-U/I-4Pt/Ni 2)
140037
Analog output modules
Slice modules XN 1 analog output
0/4 to 20 mA
XN-S3T-SBB
XN-S3S-SBB
XN-1AO-I(0/4...20MA)3)
140065
1 off
2 analog outputs
0/4 to 20 mA
XN-2AO-I(0/4...20MA)3)
140146
2 analog outputs
-10/0 to +10 V DC
XN-2AO-U(-10/0...+10VDC)3)
140066
Slice modules XNE 4 analog outputs
-10/0 to +10 V DC, 0/4 to 20 mA
Selectable for channel
– XNE-4AO-U/I4)
140034
Information relevant for export to North America
1)
Product Standards UL 508; cUL; IEC/EN 6113-2; CE marking
UL File No. E205091
UL CCN NRAQ, NRAQ7
CSA File No. UL report applies to both US and Canada
CSA Class No. -
NA Certification UL Recognized, certified by UL for use in Canada
Degree of Protection IEC: IP20, UL/CSA Type: -
2)
Product Standards IEC/EN 6113-2; CE marking
NA Certification Request filed for UL and CSA
Degree of Protection IEC: IP20, UL/CSA Type: -
3)
Product Standards UL 508; cUL; IEC/EN 6113-2; CE marking
UL File No. E205091
UL CCN NRAQ, NRAQ7
CSA File No. UL report applies to both US and Canada
CSA Class No. -
NA Certification UL Recognized, certified by UL for use in Canada
Degree of Protection IEC: IP20, UL/CSA Type: -
4)
Product Standards IEC/EN 6113-2; CE marking
NA Certification Request filed for UL and CSA
Degree of Protection IEC: IP20, UL/CSA Type: -
