168 / 439
6/20
Electronic motor protective relay
Basic Devices, Accessories
2010
CA08103002Z-EN
www.eaton.comBasicDevices,Accessories
Ordering
Length Diameter
Overload release For use with
Part no.
Article no.
Price
See price
list
Std. pack
Notes
⌀
I
r
mm mm
A
ZEV electronic motor-protective relay
•
Protection in the event of a phase failure
•
Test/off button
•
Reset button manual/auto
•
Protection with heavy starting duty
•
Trip-free release
–
–
1 – 820
DILEM…DILM820
ZEV
1)
209634
1
off
Suitable for protection of
EEx e motors.
II (2) GD
PTB 01 ATEX 3233
Observe manual
AWB2300-1433.
Current sensors
–
6
1 – 25
DILEM
DILM7…DILM25
ZEV-XSW-25
2)
209635
1
off
–
–
13
3 – 65
DILM7…DILM65
ZEV-XSW-65
2)
209636
–
21
10 – 145
DILM12…DILM150
ZEV-XSW-145
2)
209637
–
110
40 – 820
DILM40…DILM820
ZEV-XSW-820
2)
209641
Connecting cables
200 –
–
ZEV-XSW-25
ZEV-XSW-65
ZEV-XSW-145
ZEV-XSW-820
ZEV-XVK-20
1)
209643
1
off
–
400 –
–
ZEV-XSW-25
ZEV-XSW-65
ZEV-XSW-145
ZEV-XSW-820
ZEV-XVK-40
1)
209644
800 –
–
ZEV-XSW-25
ZEV-XSW-65
ZEV-XSW-145
ZEV-XSW-820
ZEV-XVK-80
1)
209645
1)
2)
Information relevant for export to North America
Information relevant for export to North America
Product Standards UL 508; CSA-C22.2 No. 14; IEC/EN 60947-4-1;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
12528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Suitable for
Branch circuits
Max. Voltage Rating 600 V AC
Degree of Protection IEC: IP20, UL/CSA Type: -
Product Standards UL 508; CSA-C22.2 No. 14; IEC/EN 60947-4-1;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
12528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Suitable for
Branch circuits
Max. Voltage Rating 600 V AC
Degree of Protection IEC: IP20, UL/CSA Type: -
See also
￫Page 6/29
ZEV....
HPL06020EN
