Electronic overload relays to 1500 A
Basic devices
2010
CA08103002Z-EN
www.eaton.comZEB65 electronic overload relay
•
Phase-failure sensitivity
•
Test/off pushbutton
•
Reset button
•
Manual/Auto reset selectable
•
Protection with heavy starting duty (Class 5-30)
Direct mounting
Without
9 – 45
1
N/O
1
NC
DILM40
DILM50
DILM65
DILM72
DIULM40
DIULM50
DIULM65
SDAINLM70
SDAINLM90
SDAINLM115
With
9 – 45
Without
20 – 100
With
20 – 100
ZEB150 electronic overload relay
•
Phase-failure sensitivity
•
Test/off pushbutton
•
Reset button
•
Manual/Auto reset selectable
•
Protection with heavy starting duty (Class 5-30)
Direct mounting
Without
20 – 100
1
N/O
1
NC
DILM80
DILM95
DILM115
DILM150
DIULM80
DIULM95
DIULM115
DIULM150
SDAINLM140
SDAINLM165
SDAINLM200
SDAINLM260
With
20 – 100
1
N/O
1
NC
Separate mounting
Without
20 – 100
1
N/O
1
NC
DILM80
DILM95
DILM115
DILM150
DIULM80
DIULM95
DIULM115
DIULM150
SDAINLM140
SDAINLM165
SDAINLM200
SDAINLM260
With
20 – 100
1
N/O
1
NC
Information relevant for export to North America
Product Standards UL 508; CSA-C22.2 No. 14; IEC/EN 60947-4-1; CE marking
NA Certification
Request filed for UL and CSA
Suitable for
Branch circuits
Max. Voltage Rating 600 V AC
Degree of Protection IEC: IP20, UL/CSA Type: -
Ground fault detection Setting range
of overload releases
Circuit symbol
Auxiliary contact
For use with
I
r
A
N/O = normally open contact
NC = normally closed contact
2 4 6 98 96
97 95
2 4 6 98 96
97 95
1 3 5 97 95
2 4 6 98 96
ZEB65, ZEB150
HPL06016EN
