6/26 Overload Relays
Accessories
2010 CA08103002Z-EN
AccessoriesOrdering
For use with Part no.
Article no.
Price
See price
list
Std. pack Notes Information relevant for export to
North America
Documentation
Overload relays
Overload monitoring of
EEx e motors
ZE… AWB2300-1425D
258704
1off German
ZB12…
ZB32…
AWB2300-1527D/GB
284910
German/English
ZB65…
ZB150…
AWB2300-1545D/GB
102065
German/English
Bases
For separate mounting
ZB32 ZB32-XEZ
278473
5off Can be snap fitted on a
top-hat rail to IEC/EN 60715
or can be screw fitted.
For ZB32-38, use
BK25/3-PKZ0 additionally.
Product Standards UL 508; CSA-C22.2 No. 14;
IEC/EN 60947-4-1; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 12528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Max. Voltage Rating 600 V AC
Degree of Protection IEC: IP20, UL/CSA Type: -
ZB65 ZB65-XEZ
278474
2off
Pushbuttons
For enclosed
Overload relay
Mounting diameter: 22.3 mm
External reset button, IP65
ZW7...
ZE
Z5
ZB12
ZB32
ZB65
ZB150
M22-DZ-B
254833
10 off Button plate, blue Product Standards UL 508; CSA-C22.2 No. 14;
IEC/EN 60947; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
ZW7...
ZE
Z5
ZB12
ZB32
ZB65
ZB150
M22-DZ-B-GB14
254834
10 off Button plate, blue RESET
Off button, IP65
ZW7...
ZE
Z5
ZB12
ZB32
ZB65
ZB150
M22-DZ-X
254835
10 off Without button plate,
add button plate.
Product Standards UL 508; CSA-C22.2 No. 14;
IEC/EN 60947; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Button plates
M22-DZ-X M22-XD-R
216423
10 off Button plate, red UL/CSA certification not required
M22-DZ-X M22-XD-R-X0
218153
Red button plate with white
circle
M22-DZ-X M22-XD-R-GB0
218194
Button plate red STOP
ZB, Z5, ZW7 HPL06026EN
