SPEEDWAY CABLE LADDER SYSTEMS
Product Finishing Key (See page 82)
Earth Braid
Ref.EBS01 (M10 BRAID)
2.0mm
1.5mm
Ladder
Type
Speedway
SW4
Speedway
SW5
Speedway
SW6
Speedway Cable Ladder System – Standard Material Gauges
GY
- Steel/Hot Dip Galvanized SS - Stainless Steel
GX
- Silicon Rich/Deep Galvanized
GY
SS
GX
GY
SS
GX
GY
SS
GX
Material
& Finish
Side Wall
Gauge
1.5mm
1.5mm
2.0mm
2.0mm
Rung Gauge
150
mm
300
mm
450
mm
600
mm
750
mm
900
mm
1050
mm
2.0mm
1.5mm
2.0mm
1.5mm
2.0mm
1.5mm
Speedway SW4
Load Deflection Data - Continuous Beam
800
600
400
200
0
1
2
3
4
5
6
DEFLECTION mm
LOAD PER SPAN KG
2m span
3m span
4m span
Key
Applicable for full range of standard widths.
Applicable for widths 150-600mm inc.
These illustrated graphs are indicative of the performance of Speedway SW
4
, SW
5
and SW
6
Cable Ladder in a typical
continuous beam installation. The loading figures have been determined by actual load tests. For detailed loading data please
contact our technical department.
Speedway SW5
Load Deflection Data - Continuous Beam
Key
Applicable for full range of standard widths.
Applicable for widths 150-750mm inc.
1200
1000
800
600
400
200
0
2
4
6
8
10
DEFLECTION mm
LOAD PER SPAN KG
3m span
5m span
6m span
4m span
6m span
Speedway SW6
Load Deflection Data - Continuous Beam
1400
1200
1000
800
600
400
200
0
2
4
6
8
10
DEFLECTION mm
LOAD PER SPAN KG
3m span
5m span
4m span
Key
Applicable for full range of standard widths.
Applicable for widths 150-750mm inc.
Applicable for widths 150, 300 & 450mm inc.
The Speedway Earth Bonding Strap (EBS01) is designed for use in
installations where an additional means of earthing or electrical
bonding is specified. The Speedway Earth Bonding Strap comprises
of a 16mm
2
tinned copper braid crimped into M10 tinned copper
end connectors. The Speedway Earth Bonding Strap is common to
Speedway SW4, SW5, & SW6.
Pre-punched holes for fixing the earth bonding strap are located at
each end of the ladder and fittings.
