The Big Unitrunk Product Guide V4

93 / 162

Stock length 3000mm.
*Other lengths, dimensions and finishes are available on
request, including Hot Dip Galvanised and Stainless Steel.
Stock length 3000mm.
*Other lengths, dimensions and finishes are available on request,
including Hot Dip Galvanised and Stainless Steel.
EasyConnect
Wire Basket*
PLEASE NOTE:
EasyConnect is also available in a 155mm side wall on request.
See page 147 for information for special profiles available.
Electro Zinc Plated
Stock length 3000mm.
*Other lengths and dimensions are available on request.
Hot Dip Galvanised*
EasyConnect
Wire Basket*
60mm side height 30mm side height
EasyConnect
Wire Basket*
Stainless Steel*
PLEASE NOTE:
Stainless Steel basket available in 304 & 316 Grades.
100mm side height
Width
mm Part Number Wire Ømm Weight
kg/m
Cross Section
(mm²)
EC 60.060 HDG
EC 60.100 HDG
EC 60.150 HDG
EC 60.200 HDG
EC 60.300 HDG
EC 60.400 HDG
EC 60.450 HDG
EC 60.500 HDG
EC 60.600 HDG
60
100
150
200
300
400
450
500
600
3.9
3.9
3.9
3.9
4.3
4.3
4.6
4.6
4.6
0.800
0.860
1.020
1.200
1.820
2.380
2.660
3.080
3.560
25.75
48.47
76.52
104.57
158.63
211.86
238.53
266.73
321.93
Length Beam
3.9
3.9
3.9
3.9
4.3
4.8
4.8
4.8
4.8
Width
mm Part Number Wire Ømm Weight
kg/m
Cross Section
(mm²)
EC 60.060 EZ
EC 60.100 EZ
EC 60.150 EZ
EC 60.200 EZ
EC 60.300 EZ
EC 60.400 EZ
EC 60.450 EZ
EC 60.500 EZ
EC 60.600 EZ
60
100
150
200
300
400
450
500
600
3.9
3.9
3.9
3.9
4.3
4.3
4.6
4.6
4.6
0.720
0.770
0.935
1.070
1.643
2.200
2.420
2.800
3.200
25.75
48.47
76.52
104.57
158.63
211.86
238.53
266.73
321.93
Length Beam
3.9
3.9
3.9
3.9
4.3
4.8
4.8
4.8
4.8
Width
mm Part Number Wire Ømm Weight
kg/m
Cross Section
(mm²)
EC 60.060 IN
EC 60.100 IN
EC 60.150 IN
EC 60.200 IN
EC 60.300 IN
EC 60.400 IN
EC 60.450 IN
EC 60.500 IN
EC 60.600 IN
60
100
150
200
300
400
450
500
600
4.0
4.0
4.0
4.0
4.4
4.4
4.4
4.4
4.4
0.740
0.840
0.970
1.140
1.740
2.100
2.300
2.460
2.830
25.50
48.16
76.16
104.16
158.13
211.75
238.46
266.95
322.15
Length Beam
4.0
4.0
4.0
4.0
4.4
4.8
4.8
4.8
4.8
Electro Zinc Plated
Width
mm Part Number Wire Ømm Weight
kg/m
Cross Section
(mm²)
EC 30.060 EZ
EC 30.100 EZ
EC 30.150 EZ
EC 30.200 EZ
EC 30.300 EZ
60
100
150
200
300
3.9
3.9
3.9
3.9
4.3
0.500
0.550
0.700
0.820
1.350
18.78
26.87
42.42
57.97
87.43
Length Beam
3.9
3.9
3.9
3.9
4.3
Electro Zinc Plated
Width
mm Part Number Wire Ømm Weight
kg/m
Cross Section
(mm²)
EC 100.150 EZ
EC 100.200 EZ
EC 100.300 EZ
EC 100.400 EZ
EC 100.500 EZ
EC 100.600 EZ
150
200
300
400
500
600
4.3
4.3
4.3
4.6
4.6
4.6
1.350
1.640
2.200
2.800
3.200
3.600
139.24
191.04
292.68
395.88
499.08
602.28
Length Beam
4.3
4.3
4.8
4.8
4.8
4.8
visit online: uk ireland
CABLE BASKET SYSTEMS
93
