The Big Unitrunk Product Guide V4

30 / 162

Galvanised Steel Lid
Ref.GSL2 50mm
Ref.GSL3 75mm
Ref.GSL4 100mm
Ref.GSL6 150mm
Ref.GSL8 200mm
Ref.GSL9 225mm
Ref.GSL12 300mm
Supplied in 3 metre lengths.
Dividing Fillets
Ref.DF2 50mm
Ref.DF3 75mm
Ref.DF4 100mm
Ref.DF6 150mm
Supplied in 3 metre lengths.
Metal Retaining Strap Flanged Coupling
Hanger Bracket (with Swing Bar)
Ref.HBL22SP(x) 50mm x 50mm
W H X X
55 85 10 20 22
Code
X
Y
X
Beam Clamp A
22
Code
Y
X
Plastic Cable Retaining Strap Hanger Bracket
Ref.HBL(x)
22
33
44
66
Code
Other sizes available on request.
Ref. CR2 /3
Ref. CR4 /6
f. R2/3 50mm x 75mm
f. R4/6 100mm x 150mm
Ref. CR2 50mm (Width)
Ref. CR3 75mm (Width)
Ref. CR4 100mm (Width)
Ref. CR6 150mm (Width)
90 60
X Y
Ref.BCA22 50mm x 50mm
Lid Fastener
Ref.LCS2 50mm
Ref.LCS3 75mm
Ref.LCS4 100mm
Available to suit 50mm, 75mm or 100mm widths.
Note: For sizes over 100mm use LCS2 x2
Sold in Pairs. Refer to the Trunking sidewall when ordering. (Example TK42 use FC22)
22
33
44
66
Code
85 55 10 20
135 85 10 20
165 115 10 20
245 165 10 20
H W X X
W
X
H
W
H
W
Window Beam Clamp
22
Code
90 103 50
X Y W
Ref.WBC22 50mm x 50mm
C/W M10 x 40 CPB (Bolt).
Product Finishing Key (See page 24)
STANDARD TRUNKING SYSTEMS
30
