Unitrunk Cable Trunking is a complete range of trunking and fittings
manufactured to standards as described in BS EN
50085-1:2005
and is
manufactured throughout in best quality hot dipped galvanised sheet steel
to BS EN
10346:2009
giving maximum protection from corrosion. Standard
Cable Trunking is manufactured and stocked in
3
metre lengths (other lengths
available on request please refer to our code guide at the back of this section).
• The Trunking has machine formed inturned, strengthening flanges.
• The lid incorporates a quick action metal locking device operated by a slotted stud. The slot indicates the
position of the locking bar. - (Note lid is secured using turnbuckle type fastener)
• Each length of Standard Trunking is supplied complete with lid, Coupling, Screws and Nuts.
• Fittings are manufactured from galvanised sheet steel to match the Trunking.
• Bends, Elbows, Tees and Intersection Boxes are complete with integral couplings.
• Special fittings such as OffSets, Risers, Unequal Tees and Bends can be made to order.
• All dimensions relate to the inside measurement.
Total Cable Management Solutions
SECTION 1
STANDARD
TRUNKING SYSTEMS
ACCREDITED TO THE FOLLOWING STANDARDS
LUL ACCREDITATION ID:
1815
