The Big Unitrunk Product Guide V4

27 / 162

Sharp Elbow
Inside Lid
Ref.SIE
Code
50 50 40 100
75 75 40 125
100 50 40 95
100 100 40 150
150 150 40 200
W H X Y
22
33
42
44
66 X
W
Y
Standard Trunking
Ref.TK22 50mm x 50mm
Ref.TK33 75mm x 75mm
Ref.TK42 100mm x 50mm
Ref.TK44 100mm x 100mm
Ref.TK66 150mm x 150mm
Unitrunk standard trunking is manufactured from pre-galvanised steel and is supplied in 3m lengths.
Other sizes and finishes are available on request (See code guide at the end of this section).
Gusset Bend
Top Lid
Ref.GTB
Code
50 50 86
75 75 115
100 50 137
100 100 137
150 150 190
W H X
22
33
42
44
66 W
X
Gusset Bend
Inside Lid
Ref.GIB
Code
50 50 30
75 75 30
100 50 30
100 100 30
150 150 30
W H X
22
33
42
44
66
X
X
W
H
Gusset Bend
Outside Lid
Ref.GOB
Code
50 50 30
75 75 30
100 50 30
100 100 30
150 150 30
W H X
22
33
42
44
66
X
W
H
Reducer
Code
75 75 50 50 152
100 50 50 50 152
100 100 75 75 152
150 150 100 100 152
33-22
42-22
44-33
66-44
W1 H1 W2 H2 X
H2
W1
H1
X
W2
Gusset Tee
Inside Lid
Ref.GIT
Code
50 50 50 150
75 75 50 175
100 50 50 150
100 100 50 200
150 150 50 250
W H X Y
22
33
42
44
66
Y
X X
W
H
Gusset Tee
Outside Lid
Ref.GOT
Code
50 50 50 150
75 75 50 175
100 50 50 150
100 100 50 200
150 150 50 250
W H X Y
22
33
42
44
66 Y
W
H
X
X
Gusset Tee
Top Lid
Ref.GTT
Code
50 50 30 120
75 75 30 145
100 50 30 165
100 100 30 170
150 150 30 220
W H X Y
22
33
42
44
66
Y
H
W
X X
We stock a considerable range of
sizes, for our full range of
dimensions refer to page 31.
Bespoke sizes available
on request
X
H
X
H X
FULL SIZE RANGE
GO TO PAGE 31
