With Multi-Compartment Trunking, dividing fillets are normally supplied
spot-welded in position, but can also be supplied loose for fixing on site
by drilling and screwing. Spot welds can be treated with Norgalv paint as
an extra on request. Purpose-made trunking can be supplied with conduit
entries at pre-determined regular intervals in sides and in dividing fillets.
Total Cable Management Solutions
SECTION 2
MULTI-COMPARTMENT
TRUNKING SYSTEMS
When trunking is mounted vertically or in the inverted position it is
recommended that Cable Supports should be fitted.
Bends, Tees, Intersections, etc, can be supplied complete with Dividing
Fillets In Tees with Top Lids and in Intersection Boxes, Cross-over Bridges
are fitted. Several example assemblies in Tees and Bends with
unequal compartments are shown in this section.
Three, four or more compartment trunking is available.
