Using the four-way diagram shown, decide what scenario best suits your situation. This will enable
you to give information about the trunking sizes you are working with and the size of each trunking
compartment. This information will then be used to fill in an Order table later in step 3.
PLEASE NOTE: A, B, C and D represent a plan view of trunking in four directions.
B
D
A C
D1 D2 D3 D4
A1
A2
A3
A4
C1
C2
C3
C4
B1 B2 B3 B4 PLEASE NOTE:
MORE SIZES AND
COMPARTMENTS
ARE AVAILABLE ON
REQUEST. CONTACT
YOUR LOCAL OFFICE
The 4-Way Diagram
To work out what you
need, you can use the
tables provided in this
catalogue or download
the Multi-Compartment
guide from our website
STEP 1:
HOWTO ORDER (Without going round the bend!)
Trunking Direction
PLEASE NOTE: This section is to be used as an aid when ordering unequally divided and TOP LID and therefore
directional Trunking Fittings. For INSIDE or OUTSIDE LID fittings all we need to know is the size
of each compartment, therefore the steps below are only applicable for TOP LID Accessories.
MULTI-COMPARTMENT TRUNKING SYSTEMS
