Top Lid TEE with underpass
taking cables from the right hand
compartment out from the rear
compartment.
10
STEP 3
STEP 4
STEP 1
STEP 2
Trunking Direction
Size of Trunking
Fitting
D
A C
Trunking Size (mm x mm)
150 x 50
A
D
150 x 50
(EXAMPLE: C)
Trunking Size 150 x 50 x2 Compartments (code: TK62x2)
Compartment Size & Cable Run
D4
(mm)
C1 C2
To...
(mm)
C3
50
From...
A1
A2
A3
100
C4 D1 D3
100
D2
50
Product Finishing Key (See page 24)
MULTI-COMPARTMENT TRUNKING SYSTEMS
