The Big Unitrunk Product Guide V4

41 / 162

STEP 3 STEP 4
STEP 1 STEP 2 Trunking Direction Size of Trunking
Fitting Compartment Size
& Cable Run
(EXAMPLE: D)
Trunking Size 200 x 100 x 3 Compartments (code: TK84x3)
10
Trunking Size (mm x mm)
200 x 100
A
D 200 x 100
D
A C
(mm)
C1 C2
To... (mm)
C3
75
From...
A1
A2
A3
75
C4 D1 D3
75
D2
75
D4
50 50
Top lid Tee with 2 No
crossover pieces to allow
cables to Tee off in the correct
order to suit the branched
trunking supply.
MULTI-COMPARTMENT TRUNKING SYSTEMS
