CODE GUIDE
STEP 3: CHOOSE SIZE
WIDTH
50
75
75
100
100
100
150
150
150
150
200
200
200
200
200
225
225
225
225
225
300
300
300
300
HEIGHT
50
50
75
50
75
100
50
75
100
150
50
75
100
150
200
50
75
100
150
225
50
75
100
150
22
32
33
42
43
44
62
63
64
66
82
83
84
86
88
92
93
94
96
99
12X2
12X3
12X4
12X6
300 200 12X8
NO OF COMPARTMENTS POSSIBLE
X2 X3 X4 SIZE CODE
300 225 12X9
300 300 12X12
STEP 2: CHOOSE PRODUCT
TK Trunking (3m lengths)
LT Lighting Trunking (3/3.5/4.5/6m lengths)
GSL Galvanised Steel Lid (Width Only)
TC Trunking Coupling
DF Dividing Fillet (loose) (Height Only)
GTB Gusset Bend (Top Lid)
GIB Gusset Bend (Inside Lid)
GOB Gusset Bend (Outside Lid)
STE Sharp Elbow (Top Lid)
SIE Sharp Elbow (Inside Lid)
SOE Sharp Elbow (OutsideLid)
GTT Gusset Tee (Top lid)
GIT Gusset Tee (Inside Lid)
GOT Gusset Tee (Outside Lid)
STT Sharp Tee (Top Lid)
SIT Sharp Tee (Inside Lid)
SOT Sharp Tee (Outside Lid)
ITB Intersection Box
TE 45° Elbow (Top Lid)
IE 45° Elbow (Inside Lid)
OE 45° Elbow (Outside Lid)
RE Reducer
FF Flared Flange
BE Blank End
FB Fire Barrier Clip
LCS Lid Clips (Strap and Stud)
FC Flanged Coupling
CS Cable Support
CES Earth Link (Copper) x 10
TCES Earth Link (Tinned Copper) x 10
CR Cable Retainer Strap x 10
STLI Socket Outlet (Single)
STL2 Socket Outlet (Double)
PES PVC Edging Strip - per metre
PRODUCT NAME CODE
STEP 4: COMPARTMENTS
STEP 1 : CHOOSE PRODUCT FINISH
PRE-GALVANISED POWDER COATED STAINLESS STEEL
STEP 5: GAUGE
Gauges conform to latest specifications. For specialist
requirements a range of gauges are available on request.
