CODE GUIDE
STEP 3: CHOOSE SIZE
WIDTH
50
75
75
HEIGHT
50
50
75
22
32
33
NO OF COMPARTMENTS POSSIBLE
X2 X3 X4 SIZE CODE
STEP 2: CHOOSE PRODUCT
LT Lighting Trunking (3/3.5/4.5/6m lengths)
GSL Galvanised Steel lid (Width Only)
TC Trunking Coupling
DF Dividing Fillet (loose) (Height Only)
GTB Gusset Bend (Top Lid)
GIB Gusset Bend (Inside Lid)
GOB Gusset Bend (Outside Lid)
STE Sharp Elbow (Top Lid)
SIE Sharp Elbow (Inside Lid)
SOE Sharp Elbow (OutsideLid)
GTT Gusset Tee (Top lid)
GIT Gusset Tee (Inside Lid)
GOT Gusset Tee (Outside Lid)
STT Sharp Tee (Top Lid)
SIT Sharp Tee (Inside Lid)
SOT Sharp Tee (Outside Lid)
ITB Intersection Box
TE 45° Elbow (Top Lid)
IE 45° Elbow (Inside Lid)
OE 45° Elbow (Outside Lid)
RE Reducer
FF Flared Flange
BE Blank End
FB Fire Barrier Clip
LCS Lid Clips (Strap and Stud)
FC Flanged Coupling
CS Cable Support
CES Earth Link (Copper) x 10
TCES Earth Link (Tinned Copper) x 10
CR Cable Retainer Strap x 10
STLI Socket Outlet (Single)
STL2 Socket Outlet (Double)
PES PVC Edging Strip - per metre
PRODUCT NAME CODE
STEP 4: COMPARTMENTS
STEP 1 : CHOOSE PRODUCT FINISH
