54 / 162
Z
SIZE
Y
X
R:
Radius
Flat
45
° Bend
Ref. KLLD 50 - 600FB45
50
75
100
150
225
300 450
600
Size
X
Y
Z
R
88 106 124 159 212 283 389 495
72 97 122 172 247 329 479 629
58 58 58 58 58 77 77 77
75 75 75 75 75 100 100 100
Z
Y
SIZE
Flat
90
° Bend
Ref. KLLD 50 - 600FB90
50
75
100
150
225
300 450
600
Size
R:
Radius
125 150 175 225 300 400 550 700
213 238 263 313 388 488 638 788
106 106 106 106 106 142 142 142
75 75 75 75 75 100 100 100
X
Y
Z
R
Reducer
Ref. KLLD/SR
Assembly space = 250mm.
Please state sizes required.
250
SIZE
Z
Flat Equal Tee
Ref. KLLD 50 - 600ET
50
75
100
150
225
300 450
600
196 221 246 296 371 446 596 746
123 148 173 223 298 373 523 673
106 106 106 106 106 106 106 106
75 75 75 75 75 75 75 75
Size
Z
X
SIZE
Y
SIZE
R:
Radius
X
Y
Z
R
Flat
4
Way Equal Intersection
Ref. KLLD 50 - 600FW
50
75
100
150
225
300 450
600
200 225 250 300 375 450 600 750
106 106 106 106 106 106 106 106
75 75 75 75 75 75 75 75
X
Z
R
Size
R:
Radius
X
X
Y
X
LIGHT DUTY CABLE TRAY SYSTEMS
Product Finishing Key (See page 24)
UK PATENTED: UK Patent number: GB2476569, IRELAND PATENT PENDING: application number:2010/0795
54
