Earth electrodes
Diameter Length Weight Part
each No.
9.0 mm 1200 mm 0.62 kg RB005
12.7 mm 1200 mm 1.18 kg RB103
12.7 mm 1500 mm 1.55 kg RB107
12.7 mm 1800 mm 1.76 kg RB116
12.7 mm 2400 mm 2.36 kg RB126†
14.2 mm 1200 mm 1.53 kg RB203
14.2 mm 1500 mm 1.88 kg RB213
14.2 mm 1800 mm 2.29 kg RB216
14.2 mm 2000 mm 2.51 kg RB217
14.2 mm 2100 mm 2.68 kg RB223
14.2 mm 2400 mm 3.00 kg RB226†
14.2 mm 3000 mm 3.79 kg RB236†
17.2 mm 1200 mm 2.19 kg RB306
17.2 mm 1500 mm 2.73 kg RB313
17.2 mm 1800 mm 3.27 kg RB316
17.2 mm 2000 mm 3.64 kg RB317
17.2 mm 2100 mm 3.83 kg RB323
17.2 mm 2400 mm 4.35 kg RB326†
17.2 mm 3000 mm 5.44 kg RB336†
Fittings
Type Weight Part
each No.
12.7 mm Coupling 0.09 kg CG177
14.2 mm Coupling 0.08 kg CG277
17.2 mm Coupling 0.13 kg CG377
12.7 mm Driving head 0.25 kg ST107
14.2 mm Driving head 0.22 kg ST207
17.2 mm Driving head 0.27 kg ST307
Earth rods to BS EN 50164-2, BS 7430
UL467 (RB126, RB226, RB236, RB326, RB336)
Unthreaded copperbond earth rod
Driving head
Rod
Taper coupling
RB226 + ST207 +
CG277
