Earth electrodes
For further information on FurseCEM®, please
contact the Furse sales office. A separate
datasheet is available.
Certain ground conditions make it difficult to
obtain a reliable earth resistance, whilst particular
installations may require a very low resistance. In
such cases, FurseCEM® provides a convenient and
permanent solution.
By adding FurseCEM® in place of sand and
aggregate, to cement, a conductive concrete is
formed. This electrically conductive medium has
many applications in the electrical/construction
industry, including RF and microwave screening,
static control and, of course, earthing, for which it
was specifically developed.
When used as a backfill for earth electrodes, FurseCEM® impregnated
concrete greatly increases the electrode’s surface area thus lowering its
resistance to earth.
CoSHH Datasheet available on request.
Topsoil
Earth Rod
Electrode
Rock ,
Sand,
Shale,
etc.
Concrete
Mix
FurseCEM®
Description Weight Part
each No.
FurseCEM ® 25 kg CM025
FurseCEM ® (supplied with cement) 25 kg CM030
Bentonite moisture retaining clay
Used as an earth-electrode backfill to reduce soil
resistivity by retaining moisture. The clay is a
sodium activated montmorillonite, which when
mixed with water swells to many times its dry
volume. It has the ability to hold its moisture
content for a considerable period of time and to
absorb moisture from the surrounding soil (e.g.
from rainfall).
CoSHH Datasheet available on request.
Topsoil
Moisture
Retaining
Earth Rod
Electrode
Rock,
Sand,
Shale,
etc.
Clay
Description Weight Part
each No.
Bentonite powder 25 kg CM015
Bentonite granules 25 kg CM015-PM
FurseCEM® conductive aggregate
Furse, Wilford Road, Nottingham, NG2 1EB • Tel: +44 (0)115 964 3700 • Email: • Web:
Tested to BS EN 50164-7
CM025
CM015
