Conductor network
Conductor
size
DC Clip
Colour
Weight Part
each No.
For use with bare tape
25 x 3 mm Brown 0.06 kg HF015
25 x 3 mm Grey 0.06 kg HF020
For use with PVC covered tape
25 x 3 mm Brown 0.06 kg HF025
25 x 3 mm Black 0.06 kg HF030
25 x 3 mm Grey 0.06 kg HF040
25 x 3 mm Stone 0.06 kg HF045
Designed to allow tape conductors to be fixed to tiled roofs without
compromising the waterproofing nature of the roof. The 500 mm tail fits
neatly between overlapping tiles and is wrapped around/fixed to the tile
lathe for secure fitting.
Slate holdfast with non-metallic DC tape clip
Designed to allow circular conductors to be fixed to tiled roofs without
compromising the waterproofing nature of the roof. The 500 mm tail fits
neatly between overlapping tiles and is wrapped around/fixed to the tile
lathe for secure fitting.
Slate holdfast with non-metallic push-in clip
Conductor
diameter
Colour Weight Part
each No.
8 mm Brown 0.03 kg HF176
8 mm Grey 0.03 kg HF191
HF040
HF191
