Conductor network
TSC-0912 - 09.10.12
Disc diameter 85 mm.
Provides a secure means of fixing flat tape conductors to single ply
polypropylene, polyethylene and PVC roof membranes using an industrial
heat gun, where solvent welding is not applicable.
Manufactured from high grade PVC, UV stabilized against degradation by
sunlight and non-brittle to prevent cold weather damage.
For dressing tool, see page 59.
Heat weldable DC tape clip
Heat weldable push-in clip
HW020-FU
HW872
Conductor
diameter
Colour Weight Part
each No.
For use with bare solid circular conductor
8 mm Brown 0.03 kg HW887
8 mm Grey 0.03 kg HW872
For use with PVC covered solid circular conductor
10 mm* Brown 0.03 kg HW886
10 mm* Grey 0.03 kg HW871
* PVC covered 8 mm conductor.
Disc diameter 85 mm.
Provides a secure means of fixing circular conductors to single ply
polypropylene, polyethylene and PVC roof membranes using an industrial
heat gun, where solvent welding is not applicable.
Manufactured from high grade PVC, UV stabilized against degradation by
sunlight and non-brittle to prevent cold weather damage.
Conductor
size
Colour Weight Part
each No.
For use with bare tape
25 x 3 mm Brown 0.03 kg HW015-FU
25 x 3 mm Grey 0.03 kg HW020-FU
For use with PVC covered tape
25 x 3 mm Brown 0.03 kg HW025-FU
25 x 3 mm Black 0.03 kg HW030-FU
25 x 3 mm Grey 0.03 kg HW040-FU
25 x 3 mm Stone 0.03 kg HW045-FU
25 x 3 mm White 0.03 kg HW050-FU
