Furse Total Solution to Earthing & Lightning Protection

57 / 300

Furse, Wilford Road, Nottingham, NG2 1EB • Tel: +44 (0)115 964 3700 • Email: • Web:
TSC-0912 - 09.10.12
Conductor
size
Colour Weight Part
each No.
For use with bare tape
25 x 3 mm Brown 0.03 kg CW015-FU
25 x 3 mm Grey 0.03 kg CW020-FU
For use with PVC covered tape
25 x 3 mm Brown 0.03 kg CW025-FU
25 x 3 mm Black 0.03 kg CW030-FU
25 x 3 mm Grey 0.03 kg CW040-FU
25 x 3 mm Stone 0.03 kg CW045-FU
25 x 3 mm White 0.03 kg CW050-FU
Conductor network
Conductor
diameter
Colour Weight Part
each No.
For use with bare solid circular conductor
8 mm Brown 0.03 kg CW887
8 mm Grey 0.03 kg CW872
For use with PVC covered solid circular conductor
10 mm* Brown 0.03 kg CW886
10 mm* Grey 0.03 kg CW871
* PVC covered 8 mm conductor.
Solvent weldable DC tape clip
Disc diameter 64 mm.
Provides a secure means of fixing conductors to single ply PVC roof
membranes. Manufactured from high grade PVC, UV stabilized against
degradation by sunlight and non-brittle to prevent cold weather damage.
For dressing tool and welding solvent, see page 59.
Clips are available for Polypropylene, Polyethylene and other roof
membranes - see page 58.
Disc diameter 64 mm.
Provides a secure means of fixing conductors to single ply PVC roof
membranes. Manufactured from high grade PVC, UV stabilized against
degradation by sunlight and non-brittle to prevent cold weather damage.
For welding solvent, see page 59.
Clips are available for Polypropylene, Polyethylene and other roof
membranes - see page 58.
Solvent weldable push-in clip
CW872
CW020-FU
